Quick Details
-
Brand Name:
-
ETU-Link
-
Use:
-
Data centers, Cloud Networks,400GE Interconnect
-
Warranty Time:
-
1 year
-
Product name:
-
100G QSFP28 Optical Transceiver
-
Connector:
-
MPO/LC
-
Data Rate:
-
100G
-
Distance:
-
100M,500M,2KM, 10KM,20KM,30KM,40KM,80KM,100KM
-
Wavelength:
-
850nm,1310nm,1270/1330nm,1295.56, 1300.05, 1304.58, 1309.14nm
-
Fiber Type:
-
SM MM
-
DDM:
-
YES
-
Operating temperature:
-
0~70℃
Quick Details
-
Type:
-
Fiber Optic Transceivers
-
Model Number:
-
100G QSFP28 Module
-
Place of Origin:
-
GUA
-
Brand Name:
-
ETU-Link
-
Use:
-
Data centers, Cloud Networks,400GE Interconnect
-
Warranty Time:
-
1 year
-
Product name:
-
100G QSFP28 Optical Transceiver
-
Connector:
-
MPO/LC
-
Data Rate:
-
100G
-
Distance:
-
100M,500M,2KM, 10KM,20KM,30KM,40KM,80KM,100KM
-
Wavelength:
-
850nm,1310nm,1270/1330nm,1295.56, 1300.05, 1304.58, 1309.14nm
-
Fiber Type:
-
SM MM
-
DDM:
-
YES
-
Operating temperature:
-
0~70℃
Product Parameters
|
100G QSFP28 SR4 100M
|
100G QSFP28 CWDM4 2KM
|
100G QSFP28 ER4 40KM
|
100G QSFP28 ZR4 80KM
|
|
100G
|
100G
|
100G
|
100G
|
|
850nm
|
CWDM
|
1294 nm- >1311 nm
|
LAN-WDM
|
|
100M
|
2KM
|
40KM
|
80KM
|
|
MPO
|
LC
|
LC
|
LC
|
|
MM
|
SM
|
SM
|
SM
|
|
DDM
|
DDM
|
DDM
|
DDM
|
|
0 to 70°C
|
0 to 70°C
|
0 to 70°C
|
0 to 70°C
|
|
Product series
|
Optical Transceiver
|
Brand
|
ETU-LINK
|
|
Type
|
100G QSFP28
|
Data Rate
|
100G
|
|
Wavelength
|
1295.56, 1300.05, 1304.58, 1309.14nm,
1310nm, 850nm, 1270/1330nm
|
Fiber Type
|
SM/MM
|
|
Max Distance
|
100M-100KM
|
Connector
|
LC/MPO
|
QSFP28
Model
QSFP28 with the same interface size as a QSFP+ module. A QSFP28 interface can use a 100GE QSFP28 optical module or a 40GE QSFP+
optical module.
optical module.
100G QSFP28
100G QSFP28 SWDM4 100m LC
Optical Transceiver
100G QSFP28 SR BiDi 100m LC
Optical Transceiver
100G QSFP28 DR 500m LC
Optical Transceiver
100G QSFP28 CWDM4 2KM LC
Optical Transceiver
100G QSFP28 PSM4 2KM MPO
Optical Transceiver
100G QSFP28 LR4 10KM LC
Optical Transceiver
100G QSFP28 LR1 BIDI 10KM LC
Optical Transceiver
100G QSFP28 ER1 BIDI 30KM LC
Optical Transceiver
100G QSFP28 ER4 30KM LC
Optical Transceiver
100G QSFP28 ER1 BIDI 40KM LC
Optical Transceiver
100G QSFP28 ER4 40KM LC
Optical Transceiver
100G QSFP28 ZR4 80KM LC Generation II
Optical Transceiver
100G QSFP28 ZR4 100KM LC Generation II
Optical Transceiver
100G QSFP28 to 25G SFP28 Converter
100G QSFP28 LR1 BIDI 20KM LC
Optical Transceiver
About 100G QSFP28
1. What is 100G QSFP28?
100G QSFP28 is designed to carry 100 Gigabit Ethernet, providing a high-density and high-speed solution for data centers and high-performance computing networks.
2. What does the 28 mean in QSFP28?
The number "28" in QSFP28 refers to the data transmission speed of 28 Gbps per channel. It represents the current industry standard for high-speed networking, offering increased bandwidth and improved performance for data-intensive applications.
3. What type of connector is QSFP28?
The two most commonly seen connector types for QSFP28 transceivers are MTP/MPO-12 and Duplex LC.
4. What is the specification of QSFP28?
The QSFP28 integrates 4 transmit and 4 receiver channels. The number 28 means each lane carries up to 28G data rate. QSFP28 supports 4x25G breakout connection, 2x50G breakout, or 1x100G depending on the type of QSFP28 transceiver used. QSFP28 transceivers include SR4, LR4, PSM4 , CWDM4 and BiDi series.
Optical Transceiver Details
Classified by Transmission Rates
Depending on transmission rates, optical modules are classified into
400G, 100G, 40G, 25G, 10G, 1G, and 100M
optical modules.
Classified by Encapsulation Types
The higher transmission rate an optical module provides, the more complex structure it has. According to the encapsulation type,optical modules are classified into
SFP, SFP+, XFP, SFP28, QSFP+, CXP, CFP, QSFP28, and QSFP-DD
. All optical modules are hot swappable.
