- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
VC-260A
-
Dimension:
-
87(W)x90(H)x50(D)mm
-
Storage:
-
N/A
-
SNR:
-
N/A
-
Output Power:
-
60W
-
Format:
-
N/A
-
Model:
-
VC-260A
-
Rate Power:
-
60W
-
controlling power range:
-
0.5W~60W
-
Volume control:
-
5 Degree(OFF,-18dB,-12dB,-6dB,0dB)
-
Adjustment:
-
Transformer
-
Material:
-
Panel: ABS
-
Net Weight:
-
330g
-
Packing Dimensions:
-
0.0234CBM, 39(W) x 30(H) x 20(D) cm, 24pcs
-
Product Name:
-
Two-wire Volume controller
-
Key word:
-
Volume controller
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Thinuna
-
Model Number:
-
VC-260A
-
Dimension:
-
87(W)x90(H)x50(D)mm
-
Storage:
-
N/A
-
SNR:
-
N/A
-
Output Power:
-
60W
-
Format:
-
N/A
-
Model:
-
VC-260A
-
Rate Power:
-
60W
-
controlling power range:
-
0.5W~60W
-
Volume control:
-
5 Degree(OFF,-18dB,-12dB,-6dB,0dB)
-
Adjustment:
-
Transformer
-
Material:
-
Panel: ABS
-
Net Weight:
-
330g
-
Packing Dimensions:
-
0.0234CBM, 39(W) x 30(H) x 20(D) cm, 24pcs
-
Product Name:
-
Two-wire Volume controller
-
Key word:
-
Volume controller
Thinuna VC-260A Public address system speaker volume control,60W pa speaker volume control knob
Product Description
Features:
The
Two-wire Volume controller
is a peripheral device used to adjust the speaker volume.
Suitable for the Two-Wire PA system without force cut function.
All models can increase the Power tunable range and reduce power consumption.
Fashionable design.
Support WM and WA.
Five-degree volume adjust.
Phoenix.
Precise adjustment，Installation fast and simple.
Standard size: It features a universal standard wall plate size.
Easy to Install: in-wall stereo volume control installs in a junction box, just like a light switch. Fits standard electrical junction/gang boxes. Makes it simple and easy to control your other products.
application scenarios：
School home store shop uses in-wall speaker volume controller.
The speaker volume controller is a peripheral device used to adjust the speaker volume.
Made of flame-retardant ABS material
Available power options: 30w, 60w, 120w.
Guaranteed quality: 2-year warranty. CE certification.
Discount will be accepted by larger quantity order.
Specification
|
Model
|
VC-230A
|
VC-260A
|
VC-2120A
|
||
|
Rate Power
|
30W
|
60W
|
120W
|
||
|
controlling power range
|
0.5W～30W
|
0.5W～60W
|
0.5W～120W
|
||
|
Volume control
|
5 Degree（OFF，-18dB，-12dB，-6dB，0dB）
|
|
|
||
|
Adjustment
|
Transformer
|
|
|
||
|
Force cut function
|
With out force cut function
|
|
|
||
|
Wiring Method
|
Phoenix. Input: HOT, COM. Output: SPK+, SPK-
|
|
|
||
|
Material
|
Panel: ABS
|
|
|
||
|
Color
|
Bright white
|
|
|
||
|
Operate temp and humidity
|
-20°C ~ 55°C; <95%
|
|
|
||
|
Dimensions
|
87(W)×87(H)×40(D)mm
|
87(W)×87(H)×50(D)mm
|
87(W)×87(H)×50(D)mm
|
||
|
Net Weight
|
157g
|
317g
|
503g
|
||
|
Install Junction Box
|
Stander Chinese-style WM or WA86 or 75 Junction Box
|
|
|
||
|
Gross Weight
|
5kg, 24pcs
|
8.5kg, 24pcs
|
9.5kg, 24pcs
|
||
|
Packing Dimensions
|
0.0216CBM, 40(W) x 18(H) x 30(D) cm, 24pcs
|
|
|
||
