L×W×H
|
7900×2050×3200mm
|
|
|
Min.ground clearance of front axle
|
450mm
|
|
|
Min.ground clearance of rear axle
|
410mm
|
|
|
Wheel tread
|
1590mm
|
|
|
Wheelbase(front/tear)
|
6120mm
|
|
Engine
|
Model
|
YN48GBZ
|
|
|
Type
|
Inline,water-cooled,four-stroke,direct injection
|
|
|
Rated power
|
92kw
|
|
|
Engine displacement
|
4.8L
|
|
|
Cylinder bore/stroke
|
108mm/132mm
|
|
|
Min.fuel-consume ratio
|
≤225g/(kw-h)
|
|
Transmission System
|
Max.speed(forward/reverse)
|
40km/h 30km/h
|
|
|
Gearbox type
|
Fixed shaft power stage
|
|
|
Torque converter
|
Single-stage single-phase three-element
|
|
|
Gears
|
Four forward four reverse
|
|
Overall Parameters
|
Overall weight
|
7450kg
|
|
|
Max.swing angle of front axle
|
±16°
|
|
|
Max.steering angle of front wheel
|
±45°
|
|
|
Blade size(length*height*thickness)
|
3350×500×18mm
|
|
|
Blade plate diameter
|
1250mm
|
|
|
Steering angle of articulated frame
|
±23°
|
|
|
Steering angle of blade
|
360°
|
|
|
Ground clearance of blade
|
450mm
|
|
|
Cutting depth of blade
|
260mm
|
|
|
Inclination angle of blade
|
Forward 47°/backward 5°
|
|
|
Sliding range of blade
|
Left 500mm/right 550mm
|
|
Hydraulic System
|
Type
|
Open-type system
|
|
|
System pressure
|
16MPa
|
|
Fill Capacity
|
Fuel
|
105L
|
|
|
Hydraulic oil
|
75L
|
|
Transmission System
|
Tire type
|
16/70-24
|
