Quick Details
-
Model Number:
-
002
-
Thickness:
-
20mm to 500mm
-
Size:
-
1600*2600; 1350*2650; 2800*5600
-
Brand:
-
Grandview
-
Resistant:
-
Excellent resistance to weather
-
warranty:
-
20 years
-
Materials:
-
PMMA, Acrylic
-
Density:
-
1.19-1.20kg/cm3
-
Packing:
-
Both sides covered by PE film or Craft paper
-
Light transmission:
-
High light transmission(93%)
-
Process:
-
Laser engraving, CNC, silk screen printing, thermoforming
-
Delivery:
-
iron pallet
Quick Details
-
Processing Service:
-
Cutting, Moulding, polishing
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
grandview
-
Model Number:
-
002
-
Thickness:
-
20mm to 500mm
-
Size:
-
1600*2600; 1350*2650; 2800*5600
-
Brand:
-
Grandview
-
Resistant:
-
Excellent resistance to weather
-
warranty:
-
20 years
-
Materials:
-
PMMA, Acrylic
-
Density:
-
1.19-1.20kg/cm3
-
Packing:
-
Both sides covered by PE film or Craft paper
-
Light transmission:
-
High light transmission(93%)
-
Process:
-
Laser engraving, CNC, silk screen printing, thermoforming
-
Delivery:
-
iron pallet
Products
Front view
Detail image
Applications
3D design
Why Choose Us
100% Bonding No Bubble，the connector/gap non yellowing
Lucite new material with 100% pureness.
Maximum 300mm can be one time cast without laminated
Offer on site installation service and technical support
Data sheet
|
PROPERTIES
|
VALUES
|
RULES
|
|
Density
|
1.19 g/cm3
|
ISO 1183-1:2012 Method A
|
|
Rockwell Hardness
|
112L
|
ISO 2039-2:1999
|
|
Tensile Modulus
|
3150MPa
|
EN ISO 527:2012
|
|
Tensile Strength
|
80.0MPa
|
EN ISO 527:2012
|
|
Tensile Strain at Break
|
3.2%
|
EN ISO 527-1:2012
|
|
Water Absorption
|
0.20%
|
ISO 62:2008 Method 1
|
|
Total Luminous Transmittance
|
93.4%
|
ISO 13468-1:1996
|
|
Vicat Softening Temperature
|
105℃
|
ISO 306:2013 Method B50
|
|
Light Ageing Test- UV Exposure
|
Grey scale: 5
|
ISO 4892-3:2016 Cycle 1
|
|
Mean Coefficient of Linear Thermal Expansion
|
72×10-6 K-1
|
ISO 11359-1:2014
|
|
Compressive Stress at Yield
|
129MPa
|
EN ISO 604:2003
|
|
Flexural Strength
|
120MPa
|
ISO 178:2013
|
|
Compressive Yield Strength
|
111MPa
|
ASTM D695-15
|
|
Compressive Modulus
|
3450MPa
|
ASTM D695-15
|
|
Shear Strength
|
59.7MPa
|
ASTM D732-17
|
|
Deflection Temperature under Load
|
100.2℃
|
ASTM D648-18 Method B
|
|
Modulus Elasticity
|
2810MPa
|
ASTM D695-15
|
