Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
oddly
-
Model Number:
-
OY-T580E
-
Warranty:
-
36 Months
-
Rim Diameter:
-
12" -30"
-
Max. wheel diameter:
-
1200mm/47''
-
Max. wheel width:
-
3"-13"
-
Net weight:
-
380kg
-
Gross Weight:
-
420kg
-
Packing size:
-
1230x1150x1850mm
Quick Details
-
Motor Power:
-
0.8/1.2KW
-
Operating Pressure:
-
8-10bar
-
Power Supply:
-
415V/380V/240V/220V/110V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
oddly
-
Model Number:
-
OY-T580E
-
Warranty:
-
36 Months
-
Rim Diameter:
-
12" -30"
-
Max. wheel diameter:
-
1200mm/47''
-
Max. wheel width:
-
3"-13"
-
Net weight:
-
380kg
-
Gross Weight:
-
420kg
-
Packing size:
-
1230x1150x1850mm
Product Description
Dimensions
Specification
|
Rim Diameter
|
12”-30”
|
|
Maximum Wheel Diameter
|
1200mm
|
|
Wheel Width
|
3”-13”
|
|
Operating Pressure
|
8-10bar
|
|
Working Voltage
|
415V/380V/220V/110V
|
|
Motor power
|
0.8/1.2KW
|
|
Bead Breaker Force
|
1400kg
|
|
Max lifting weight
|
80kg
|
|
Net weight
|
380kg
|
|
Gross weight
|
420kg
|
|
Packing size
|
1230x1150x1850mm
|
1.
Right side assist arm,two bead breaking disk, high performance in working RSC,run-flat, low profile tyres.The bead breaking disc can move independently
2.
ZD 05 leverless system, Nexion patented. Capacity 12-26inch, adjustment free.
3.
Center post locking mechanism
4.
Standard with bead breaking arm for normal tyres.Two capacities realized by help of adjustment.Two lever arms.
Anti-seize design bead breaking blade. 5. Diameter 200mm stainless steel cylinder,with force of 2800kg 6. High torque gearbox.
Anti-seize design bead breaking blade. 5. Diameter 200mm stainless steel cylinder,with force of 2800kg 6. High torque gearbox.
Packing & Delivery
Plywood,export standard packing.
By sea or by air
