Quick Details
-
Brand Name:
-
KDZD
-
Model Number:
-
KDWS-14
-
Dew point measurement range:
-
-80 ℃ to+20 ℃
-
Measurement accuracy:
-
± 0.5 ℃ (-60 ℃~+20 ℃); ± 1.0 ℃ (-80 ℃ to -60 ℃)
-
Dew point response time (+20 ℃):
-
63% takes 5 seconds
-
Environmental temperature:
-
-40 ℃~+60 ℃
-
Environmental humidity:
-
0-100% RH
-
Display device:
-
3.5-inch color LCD display
-
Power supply:
-
AC 220V with built-in rechargeable battery
-
Battery performance:
-
Used for more than 10 hours.
-
Pressure:
-
≤ 1.5 Mpa
-
Resolution:
-
0.01 ℃ or 0.1PPM
Quick Details
-
Warranty:
-
1 YEAR
-
Power:
-
Electronic
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
KDZD
-
Model Number:
-
KDWS-14
-
Dew point measurement range:
-
-80 ℃ to+20 ℃
-
Measurement accuracy:
-
± 0.5 ℃ (-60 ℃~+20 ℃); ± 1.0 ℃ (-80 ℃ to -60 ℃)
-
Dew point response time (+20 ℃):
-
63% takes 5 seconds
-
Environmental temperature:
-
-40 ℃~+60 ℃
-
Environmental humidity:
-
0-100% RH
-
Display device:
-
3.5-inch color LCD display
-
Power supply:
-
AC 220V with built-in rechargeable battery
-
Battery performance:
-
Used for more than 10 hours.
-
Pressure:
-
≤ 1.5 Mpa
-
Resolution:
-
0.01 ℃ or 0.1PPM
|
Technical parameter
|
|
|
|
Dew point measurement range
|
-80 ℃ to+20 ℃
|
|
|
Dew point measurement accuracy
|
± 0.5 ℃ (-60 ℃~+20 ℃); ± 1.0 ℃ (-80 ℃ to -60 ℃)
|
|
|
Dew point response time (+20 ℃):
|
63% takes 5 seconds; 0% takes 45 seconds (-60 ℃ to+20 ℃); 63% takes 10 seconds; 90% takes 240 seconds (+20 ℃ to -60 ℃)
|
|
|
Environmental temperature
|
-40 ℃~+60 ℃
|
|
|
Environmental humidity
|
0-100% RH
|
|
|
Display device
|
3.5-inch color LCD display
|
|
|
Power supply
|
AC 220V with built-in rechargeable battery
|
|
|
Battery performance
|
Charging time: 20 hours; Used for more than 10 hours.
|
|
|
Pressure
|
≤ 1.5 Mpa
|
|
|
Resolution
|
0.01 ℃ or 0.1PPM
|
|
|
Weight
|
5 kilograms
|
|
|
Size
|
250 x 150 x 300mm
|
|
|
Working temperature
|
-40 ℃~+60 ℃
|
|
|
Storage temperature
|
-40 ℃~+80 ℃
|
|
Technical characteristics
(1) Self calibration: The sensor probe can automatically calibrate the zero point, automatically eliminating system errors caused by zero and drift, ensuring the accuracy of each measurement, and avoiding the tedious annual calibration.
(2) Fast gas saving: After starting the machine and entering the measurement state, the dew point measurement time for each SF6 gas is about 2 minutes.
(3) Self locking joint: Adopting Germany's original imported self locking joint, safe and reliable, without air leakage.
(4) Data storage: Adopting a large capacity design, it can store up to 200 sets of test data.
(5) Curve function: The large screen curve displays the dew point measurement process.
(6) Clear display: The color LCD screen directly displays dew point, micro water (ppm), ambient temperature, ambient humidity, time, and date.
(7) RS232 interface: can be connected to a PC serial port for data transmission.
(8) Built-in power supply: Equipped with a 4Ah rechargeable lithium battery, it can work continuously for 10 hours when fully charged at once.
