Quick Details
-
Model Number:
-
IBA-14D
-
Mechanical Life:
-
50000 Cycles
-
Product Name:
-
Toggle Switch
-
Terminal:
-
3 Pin Solder Terminal
-
Housing Color:
-
black
-
Switch Type:
-
SPDT ( Latching )
-
Position:
-
3
-
Number of Contact Terminals:
-
3
-
Material:
-
Metal, Plastic
-
Mounting Hole:
-
M12
-
Operating Temp:
-
-25°C to +85°C
-
Product type:
-
mini toggle switch
Quick Details
-
Max. Voltage:
-
125VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ABILKEEN
-
Model Number:
-
IBA-14D
-
Mechanical Life:
-
50000 Cycles
-
Product Name:
-
Toggle Switch
-
Terminal:
-
3 Pin Solder Terminal
-
Housing Color:
-
black
-
Switch Type:
-
SPDT ( Latching )
-
Position:
-
3
-
Number of Contact Terminals:
-
3
-
Material:
-
Metal, Plastic
-
Mounting Hole:
-
M12
-
Operating Temp:
-
-25°C to +85°C
-
Product type:
-
mini toggle switch
Product Specification
EASY TO USE
Quick through-panel mounting into 1/2″ cutout hole. SPDT toggle switches have 3 screw terminals for reliable connections for up to 2 separate circuits. The 3 pin single pole, double throw design also allows for no-hassle toggling between loads.
VERSATILE
Rated for 20A at 125VAC and 15A at 250VAC. Also work for 12VDC. Great for controlling automotive, off-road, and marine electrical accessories. Or use it for electrical switching of industrial equipment.
Waterproof cover
Simply fold the ringlet (used as a seal) and screw the boot atop the toggle switch handle. Works great in wet and challenging environments – keeps dust and moisture away from your switch. More types are available.
|
Product Name
|
Toggle Switch
|
|
|
||
|
Brand Name
|
ABILKEEN
|
|
|
||
|
Items
|
T6001U
|
|
|
||
|
Mounting Hole
|
M6
|
|
|
||
|
Operation Type
|
ON OFF
|
|
|
||
|
Working Temperature
|
-25 to 80°C
|
|
|
||
|
Material
|
Metal and plastic
|
|
|
||
|
Dielectric strength
|
1000 V RMS (min)
|
|
|
||
|
Accessory hardware
|
Metal washer, Nameplate, Mounting nut
|
|
|
||
