CM1 Manufacturer Iot Smart Cabinet Door Lock Home Assistant Wireless RFID BLE Reader

CM1 Manufacturer Iot Smart Cabinet Door Lock Home Assistant Wireless RFID BLE Reader

FOB Reference Price: Get Latest Price

≥1 Pieces

US $0.1

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

RFID:: Mifare plus, mifare, DESFire EV1/EV2, ISO14443B, NFC, HID

Secure Interface:: SAM Slot & Secure IC EAL5+ Level

BLE wireless communication:: BLE 5.3 Master & Slave mode, Beacon, Thread, Zigbee, Mesh

Communication Interface:: WiFi, BLE 5.3, USB

Mechanical Keypad:: 12 digit keypad

Memory:: 4M

Indicator:: Buzzer and Bio-color LED

Power:: 3V, 4 * battery

Input Output:: GPI/O * 8

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: Civintec

Model Number:: Smart CM1

RFID:: Mifare plus, mifare, DESFire EV1/EV2, ISO14443B, NFC, HID

Secure Interface:: SAM Slot & Secure IC EAL5+ Level

BLE wireless communication:: BLE 5.3 Master & Slave mode, Beacon, Thread, Zigbee, Mesh

Communication Interface:: WiFi, BLE 5.3, USB

Mechanical Keypad:: 12 digit keypad

Memory:: 4M

Indicator:: Buzzer and Bio-color LED

Power:: 3V, 4 * battery

Input Output:: GPI/O * 8

Product Overview

Smart CM1 is new generation of wireless high-performance multi technology platform providing an ultra-low battery-operated power consumption design containing the latest wireless interfacing and identification technologies for a wide range of wireless electric lock, asset tracking and different handheld applications.

Smart CM1 supports almost all RFID 13.56 MHz contactless technologies, together with NFC and BLE a broad range of credentials and Mobile ID tokens. Smart CM1 is with memory to store the data and can reliably gather the data and safely transmit and exchange data wirelessly via WiFi or BLE to a central point for identification and use. Multi technology platform Smart CM1 is made for to suits individual project requirements and offer a flexibility and sustainable integration possibility. Smart CM1 is a turn key ready platform highly recommended for both hardware and software customization from embedded software, server software to mobile credential software demo, and SDK to ease customer’s integration.

Product Features

Advantages

- Mobile phone credential identification via

NFC and BLE

- Multi-standard RFID smart cards, with SAM

for EAL5+ encryption

- Rich I/O port for electric lock control
- With memory for local data storage

- Low power wireless network design
- BLE 5.3 with Master & Slave mode, Beacon,

Thread, Zigbee and Mesh functions
- Embedded software development
- Software application development

Specifications

Memory	4M BYTE
Power Supply	- USB - 3V / 4 * battery
RFID ISO Standard & Cards	13.56MHz ISO14443A, ISO15693 and ISO18092 standard - Mifare Classic CSN & Sector - DESfire EV1/EV2/EV3(2k/4k/8k) CSN & Sector - Ultralight/Ultralight C CSN & Sector - Mifare plus S,X CSN & Sector - NFC tag - HID iCLASS CSN
Secure Interface	- Optional SAM slot ISO7816 T=0, T=1; - Support SAM AV2 for 13.56MHz read/write EAL5+ encryption - Secure IC for MCU communication protection EAL5+ Level
Mobile Phone Communication	- NFC mobile phone - BLE 5.3
Mechanical Keypad	12 digit keypad
Communication Interfaces	- WiFi - BLE 5.3 (Master & Slave mode, Beacon, Thread, Zigbee, Mesh) - USB
Indicators	Buzzer and Bio-color LED
Input/Output	GPI/O * 8
Operating Temperature	-20℃~60℃
Configuration Methods	Configuration card, reader tool software or factory configured readers.
