Quick Details
-
Warranty:
-
1 Year
-
Brand Name:
-
Jutai
-
Model Number:
-
JT4503-1240A
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
4 Bar
-
Cable Length:
-
Can be customized
-
Outlet Size:
-
G1/2
-
Power:
-
13W
-
Usage:
-
Water
-
Max working temperature:
-
≤70℃
-
Theory:
-
Centrifugal pump
-
Motor:
-
DC Brushless Motor
-
Impeller:
-
Open Impeller
-
Pump Type:
-
ABS Plastic Shell
-
Color:
-
Black
-
Shaft:
-
Ceramic
-
Standard or Nonstandard:
-
Nonstandard
-
IP grade:
-
IP68
Quick Details
-
Application:
-
Other
-
Pressure:
-
Low Pressure
-
Voltage:
-
12VDC
-
Warranty:
-
1 Year
-
Brand Name:
-
Jutai
-
Model Number:
-
JT4503-1240A
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
4 Bar
-
Cable Length:
-
Can be customized
-
Outlet Size:
-
G1/2
-
Power:
-
13W
-
Usage:
-
Water
-
Max working temperature:
-
≤70℃
-
Theory:
-
Centrifugal pump
-
Motor:
-
DC Brushless Motor
-
Impeller:
-
Open Impeller
-
Pump Type:
-
ABS Plastic Shell
-
Color:
-
Black
-
Shaft:
-
Ceramic
-
Standard or Nonstandard:
-
Nonstandard
-
IP grade:
-
IP68
1. PWM speed control ,Voltage range :12-24V . Hmax :6m . Qmax :1000LPH
2.It passed the Salt Spray Test and aging test .
3. Long lifetime: Over 20000 hours.
4. Heavy duty work: Can run a whole day and night continuously.
5. Low noise, within 42 db
6. 100% QC inspection Before Shipment.
7. CE/ROHS, ISO9001 certificate.
8. Anti-vibration pads can be supplied.
9. It is better to operate in pure water to ensure its lifespan.
|
Model Character
|
JT4503-1240A
|
|
Rated working voltage
|
12VDC
|
|
Start voltage
|
10VDC
|
|
Rated power
|
13W
|
|
Rated current
|
1100±150(mA)
|
|
Max static water head
|
400±50cm
|
|
Max static flow rate
|
680±70L/H
|
|
Lifespan
|
Continuous operation under normal working surrounding>20000H
|
|
Working Environment
|
PH value: PH5-10(weak acid and weak base), workable both on land and in water.
|
|
Max noise
|
Under normal working condition,(1meter over the test instrument)<42dB
|
|
Max working temperature
|
Under room temperature surroundings, fluid medium temperature≤70℃
|
|
IP grade
|
IP68
|
|
Others
|
It passed the Salt Spray Test
|
|
Color
|
Black
|
|
Pump dimensions
|
L82.5*W66.0*H69.3 (mm)
|
|
Inlet/Outlet Outer Diameter
|
G1/2
/
G1/2
|
|
Application
|
Fountain, aquarium, pool, water tank, humidifier, solar water circulation,etc.
|
Q: Is your company a factory or a trading company?
A: We are the original manufacturer in Shenzhen of China,specialized in DC brushless water pumps over seven years.Total workers is over 300,the plant covers an area of 8000 square meters.
Q: What is your payment method?
A: TT, L/C, Western Union,Money Gram,DA,DP, Alipay are acceptable.
Q: Do your products come with warranty?
A: Our guarantee is TWO YEARS from the date you receive the goods. During the guarantee period, we are able to offer free-maintenance; technology support,etc.
Q:Do you accept sample order? What is your MOQ( Mini order quantity)?
A:
Sample order or trial order is accept,but we will charge a little sample cost.
Q: What shipping ways you can offer?
A: By International Express/air/sea accord
i
ng to customers`requirements, we have our own shipping agent for your reference,you are also freely to ask us.
Q: What is your lead time of bulk quantity and samples?
A: Sample lead time is normally 2-3 working days(we need to make samples(some models have no stock) according to customer`s requirement of specifications), as for bulk quantity, around 15 working days or more, according to the quantity.
Q: Can you offer OEM service?
A: Both OEM and ODM services can be offered.Please feel free to contact us for more details.
