Quick Details
-
Model Number:
-
fiber glass
-
Weight:
-
100g-1800g
-
Width:
-
1m/ 1.2m/ 1.5m/ 1.8m
-
Standing Temperature:
-
550° / 1000°
-
Type:
-
Fiberglass Industrial Cloth
-
Material:
-
100% Fiberglass
-
Thickness:
-
0.1 mm - 0.8 mm
-
Roll Length:
-
30m, 50m, 100m, 200m
-
Colors:
-
White/Gold or custom
-
Knitting type:
-
Plain woven/ twill woven
-
Features:
-
Insulated,Heat resistant,Corrosion resistant,High mechanical strength
-
Certificates:
-
EN1869:1997
-
Packing:
-
Polyethylene Bag+cartons+pallet
-
Samples:
-
A4 Size Sample
Quick Details
-
Application:
-
Wall/Roof covering Cloth
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Mingchen
-
Model Number:
-
fiber glass
-
Weight:
-
100g-1800g
-
Width:
-
1m/ 1.2m/ 1.5m/ 1.8m
-
Standing Temperature:
-
550° / 1000°
-
Type:
-
Fiberglass Industrial Cloth
-
Material:
-
100% Fiberglass
-
Thickness:
-
0.1 mm - 0.8 mm
-
Roll Length:
-
30m, 50m, 100m, 200m
-
Colors:
-
White/Gold or custom
-
Knitting type:
-
Plain woven/ twill woven
-
Features:
-
Insulated,Heat resistant,Corrosion resistant,High mechanical strength
-
Certificates:
-
EN1869:1997
-
Packing:
-
Polyethylene Bag+cartons+pallet
-
Samples:
-
A4 Size Sample
Products Description
|
Type
|
|
|
Thickness
|
0.1mm-0.8mm
|
|
Width
|
1 m, 1.2 m, 1.5 m, 1.8 m
|
|
Roll length
|
30m, 50m, 100m, 200m
|
|
Knitting type
|
Plain woven/ twill woven
|
|
Glass Yarn Type
|
E-Glass
|
|
Advantages
|
good insulation, heat resistance,
corrosion resistance, high mechanical strength |
|
Applications
|
Widely used in industrial insulation, thermal insulation, anticorrosion, fire protection, coating, composite materials deep processing.
|
|
Model
|
Texture
|
Densit
（/cm）
|
Width
（/cm）
|
Weight
（g/㎡）
|
Thickness
（mm）
|
Temperature
|
|
2523
|
Plain woven
|
12*8
|
100-216
|
400
|
0.35
|
550℃
|
|
EW135
|
Plain woven
|
10*9
|
100
|
135
|
0.14
|
550℃
|
|
EW200
|
Plain woven
|
7.5*7
|
100
|
200
|
0.2
|
550℃
|
|
EW280
|
Plain woven
|
11*9
|
100-216
|
280
|
0.21
|
550℃
|
|
EW330
|
Plain woven
|
15*9
|
100-216
|
335
|
0.28
|
550℃
|
|
EW480
|
Plain woven
|
10*7
|
100-216
|
480
|
0.36
|
550℃
|
|
EW580
|
Plain woven
|
8*6
|
100-216
|
580
|
0.48
|
550℃
|
|
EW720
|
Plain woven
|
8*5
|
100-216
|
720
|
0.58
|
550℃
|
|
CW100
|
Plain woven
|
17*13
|
105
|
100
|
0.1
|
550℃
|
|
CW140
|
Plain woven
|
12*9
|
100-152
|
140
|
0.14
|
550℃
|
|
CW170
|
Plain woven
|
9*8
|
102
|
170
|
0.17
|
550℃
|
|
CW260
|
Plain woven
|
12*10
|
129
|
220
|
0.26
|
550℃
|
|
CW950
|
Plain woven
|
12*5
|
100
|
950
|
0.95
|
550℃
|
|
3732
|
Twill woven
|
18*13
|
100-180
|
430
|
0.43
|
550℃
|
|
3784
|
Satin woven
|
18*12
|
100-180
|
840
|
0.8
|
550℃
|
|
3786
|
Satin woven
|
18*13
|
100-180
|
1300
|
1.2
|
550℃
|
|
3788
|
Satin woven
|
18*13
|
100-180
|
1700
|
1.7
|
550℃
|
|
CW270
|
Satin woven
|
12*11
|
100-150
|
270
|
0.27
|
550℃
|
|
CW840
|
Satin woven
|
10*10
|
100-152
|
200
|
0.8
|
550℃
|
|
EW660
|
Twill woven
/Satin woven
|
18*13
/14*11
|
100-150
|
660
|
0.65
|
550℃
|
|
PW800
|
Plain woven
|
18*13
|
1002
|
800
|
0.8
|
550℃
|
|
PW1000
|
Plain woven
|
18*13
|
102
|
1000
|
1
|
550℃
|
|
Wire cloth
|
Plain woven
|
14.4*4.5
|
100-127
|
1100
|
1
|
550℃
|
Product properties:
1. Temperature resistance: it can continuously work under -70 ~ 260°C
2. Weatherability: resistant to ozone, oxygen, sunlight and aging, long using life up to 10 years
3. Good electric insulator, dielectric constant 3 - 3.2, breaking down voltage between 20 - 50kV/mm
1. Temperature resistance: it can continuously work under -70 ~ 260°C
2. Weatherability: resistant to ozone, oxygen, sunlight and aging, long using life up to 10 years
3. Good electric insulator, dielectric constant 3 - 3.2, breaking down voltage between 20 - 50kV/mm
