Quick Details
-
Brand Name:
-
Rowdai
-
Voltage:
-
380v 50hz
-
Power:
-
11000
-
Dimension(L*W*H):
-
1790*1730*1430
-
Weight:
-
3000
-
Max.rolling force:
-
280KN
-
radial rolling diameter:
-
90mm
-
Max. rolling pitch:
-
8mm
-
Max.width of rolling wheel:
-
160mm
-
spindle center distance:
-
150-300mm
-
spindle speed:
-
20.25.31.41.51.64r/min
-
rolling power:
-
11kw
-
hydraulic power:
-
5.5kw
-
cooling power:
-
90w
-
dimension:
-
1790*1730*1430mm
Quick Details
-
Place of Origin:
-
Henan, China
-
Application:
-
threads rolling
-
Marketing Type:
-
New Product 2022
-
Brand Name:
-
Rowdai
-
Voltage:
-
380v 50hz
-
Power:
-
11000
-
Dimension(L*W*H):
-
1790*1730*1430
-
Weight:
-
3000
-
Max.rolling force:
-
280KN
-
radial rolling diameter:
-
90mm
-
Max. rolling pitch:
-
8mm
-
Max.width of rolling wheel:
-
160mm
-
spindle center distance:
-
150-300mm
-
spindle speed:
-
20.25.31.41.51.64r/min
-
rolling power:
-
11kw
-
hydraulic power:
-
5.5kw
-
cooling power:
-
90w
-
dimension:
-
1790*1730*1430mm
Product Description
Specification
|
Model
|
Z28-80
|
Z28-200D
|
Z28-280
|
|
Max. rolling force
|
80KN
|
200KN
|
280KN
|
|
Radial rolling diameter
|
30mm
|
60mm
|
90mm
|
|
Max.rolling pitch
|
4mm
|
6mm
|
8mm
|
|
Max.diameter of rolling wheel
|
170mm
|
210mm
|
220mm
|
|
Thread roller aperture
|
54mm
|
75mm
|
75mm
|
|
Max.width of rolling wheel
|
100mm
|
160mm
|
160mm
|
|
Spindle center distance
|
120-240mm
|
120-240mm
|
150-300mm
|
|
Spindle tilt angle
|
±50°
|
±10°
|
±10°
|
|
Spindle speed
|
36.47.60.78(r/min)
|
20.25.31.41.51.64(r/min)
|
20.25.31.41.51.64(r/min)
|
|
Rolling power
|
4kw
|
11kw
|
11kw
|
Packing & Delivery
Wooden case for bolts threading machine thread rolling machine
