1, Ordinary grinding can be performed, but also for fine crushing and fine crushing. Widely used in large and medium-sized feed mills, high quality feed production and alcohol plant, citric acid factory, food factory, etc.
2, Finished product granularity more fine and uniform: Φ3 mm sieve can reachΦ2 mm mesh fineness, Selects imported SKF high quality bearing, low operating temperature rise;
3, Compared with weight is lighter and fat content is higher, it greatly improves the sieving rate, yield than other shredder similar power increased by 15% ~ 20%; Discharging unobstructed, high efficiency.
4, The machine uses motor direct drive, scientific and reasonable hammer sieve clearance, crushing chamber adopts the secondary crushing technology.
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
Local voltage
-
Power:
-
30KW
-
Weight:
-
800 KG
-
Dimension(L*W*H):
-
Actual
-
Product name:
-
hammer mill for maize
-
Application:
-
Grain Feed, sorghum
-
Capacity:
-
4-7T/H
-
Color:
-
White and light green
-
Material:
-
Steel and stainless steel
-
Motor:
-
Siemens(Beide) Brand
-
Function:
-
Grinding
-
Rotor diameter:
-
675mm
-
Processing Types:
-
Grinding the raw material
-
Machine name:
-
Feed hammer mill
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
YUDA
-
Production Capacity:
-
High
-
Voltage:
-
Local voltage
-
Power:
-
30KW
-
Weight:
-
800 KG
-
Dimension(L*W*H):
-
Actual
-
Product name:
-
hammer mill for maize
-
Application:
-
Grain Feed, sorghum
-
Capacity:
-
4-7T/H
-
Color:
-
White and light green
-
Material:
-
Steel and stainless steel
-
Motor:
-
Siemens(Beide) Brand
-
Function:
-
Grinding
-
Rotor diameter:
-
675mm
-
Processing Types:
-
Grinding the raw material
-
Machine name:
-
Feed hammer mill
Product parameter
|
Model
|
Power(KW)
|
Capacity(T/H)
|
Rotor diameter(MM)
|
Rotate speed(RPM)
|
Weight (KG)
|
|
SFSP50-1
|
7.5
|
1-2
|
500
|
3540
|
600
|
|
SFSP50-1
|
15
|
1-2
|
500
|
3540
|
610
|
|
SFSP50-2
|
11
|
1-2
|
500
|
3540
|
600
|
|
SFSP50-2
|
18.5
|
1-2
|
500
|
3540
|
610
|
|
SFSP56×36
|
15
|
1.5-3
|
560
|
2950
|
680
|
|
SFSP56×36
|
22
|
3-4
|
560
|
2950
|
690
|
|
SFSP56×36
|
30
|
3-5
|
560
|
2950
|
700
|
|
SFSP56×40
|
30
|
4-6
|
560
|
2950
|
800
|
|
SFSP56×40
|
37
|
5-7
|
560
|
2950
|
810
|
Product details
SFSP
series hammer mill for maize
Siemens Beide Motor:
Imported motor,suitable for hammer mill.
SKF bearing:
This kind of bearing can using for a long time.Best Quality.
Feed Inlet:
Large opening design,convenient feeding
Hammer
piece
:
Carbon steel materials,can according to customers' requirements to change.Easy to change.
For targeted help, please tell us:
1) What is the raw material you want to process?
2) What about the capacity?
3) Will you need a single hammer mill machine?
4) Will you need a complete set of animal feed production line?
