Quick Details
-
Model Number:
-
STAGE M15
-
Dimension:
-
W610mm*D475.5mm*H368.2mm
-
Storage:
-
---
-
SNR:
-
N/A
-
Output Power:
-
550W
-
Format:
-
---
-
Product Name:
-
Floor monitor loudspeakers
-
Rated Power:
-
550W
-
Peak power:
-
2200W
-
Max power:
-
1100W
-
Nominal sensitivity(1W@1m):
-
99dB
-
Nominal impedance:
-
8-Ohms
-
Nominal coverage pattern(-6dB):
-
90°H x 90°V
-
Speaker unit:
-
LF 15" x 1 + HF1.73" x 1
-
Enclosure:
-
18mmT high quality birch plywood and paint spraying metal mesh
-
Applications:
-
Multi-purpose,bars, stadiums
Quick Details
-
Warranty:
-
3 months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Deken
-
Model Number:
-
STAGE M15
-
Dimension:
-
W610mm*D475.5mm*H368.2mm
-
Storage:
-
---
-
SNR:
-
N/A
-
Output Power:
-
550W
-
Format:
-
---
-
Product Name:
-
Floor monitor loudspeakers
-
Rated Power:
-
550W
-
Peak power:
-
2200W
-
Max power:
-
1100W
-
Nominal sensitivity(1W@1m):
-
99dB
-
Nominal impedance:
-
8-Ohms
-
Nominal coverage pattern(-6dB):
-
90°H x 90°V
-
Speaker unit:
-
LF 15" x 1 + HF1.73" x 1
-
Enclosure:
-
18mmT high quality birch plywood and paint spraying metal mesh
-
Applications:
-
Multi-purpose,bars, stadiums
Deken STAGE M15 Professional Stage Activity 2 Unit 2 Way 15 Inch Coaxial Inverting Passive Speakers 550w Floor Monitor Speaker
Product Description
Specification
|
System type
|
2 unit 2-way coaxial inverting
|
|
Rated power
|
550W
|
|
Max Power
|
1100W
|
|
Peak power
|
2200W
|
|
Nominal impedance
|
8 Ω
|
|
Recommended power amplifier output rating
|
600W—1000W@8 Ω
|
|
Nominal sensitivity（1W@1m）
|
99dB
|
|
Max SPL（Pmax@1m）
|
126dB@550W(129 dB @900W,)
|
|
Frequency response（-10dB）
|
54Hz—20KHz
|
|
Nominal coverage pattern（-6dB）
|
90°H×90°V
|
|
Speaker component
|
Ferrite HF driver（44mm voice coil）×1
Ferrite LF driver 15″(380mm diameter,65mm voice coil) ×1
|
|
Crossover modes
|
Passive 2-way
|
|
Connector
|
Speakon NL4×2（PIN1+/2+POS. PIN1-/2-NEG.）
|
|
Enclosure
|
18mm（0.7″）High quality birch plywood and paint spraying metal mesh
|
|
Color
|
Default is black, other colors can be customized
|
|
Dimensions
|
W610mm x D475.5mm x H368.2mm
|
|
Weight(each)
|
21.95kg
|
|
Shipping weight
|
24.25kg
|
|
Reference applications:
|
Multipurpose halls, bars, stadiums, all the applications that need to be monitored
|
Project Solutions
Suitable occasions:
Airports, Bus stations, Hotels, Office buildings, Gyms, Villas, Homes, Schools, Bar spas,KTV ,Saunas, Parks.......
About us
Production Flow
Recommend Products
The main products：
Speaker：
Ceiling Speaker, Professional Speaker,Blue tooth Speaker,Wall Mount Speaker，Column Speaker, Horn Speaker,Conference Speaker，Active Speaker,Garden Speaker，Lawn Speaker , Rock Stone Speaker, Landscape Speaker ,Subwoofer Speaker，Sound System etc.
Amplifier：
Pa Amplifier，Blue tooth Amplifier，4 Channels Amplifier，FM Amplifier，Class D amplifier，Audio amplifier，Professional Amplifier etc.
Public Address System：
IP network system，IP Network Host，IP Network Soft，IP Amplifier，IP Speaker，IP Microphone.
Our customer feedback
Packing & Delivery
FAQ
Q1. Can I have a sample order for loudspeaker?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 2-5 days, mass production time needs 3-4 weeks for order quantity more than
Q3. Do you have any MOQ limit for loudspeaker order?
A: 5PCS MOQ, 2pcs for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by Sea. It usually takes 30-45 days to arrive. Airline also optional.
Q5. How to proceed an order for loudspeaker?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on loudspeaker product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
