Quick Details
-
Model Number:
-
2W
-
Brand Name:
-
Acarps
-
Body material:
-
Stainless Steel
-
Voltage:
-
12VDC, 220VAC, , 24VAC, 24VDC
-
Connection type:
-
BSP (G)
-
Working pressure:
-
0-16bar
-
Operation:
-
Three Wire Two Control
-
Temperature:
-
<95℃
-
Running Time:
-
5-15 Seconds
-
Structure Forms:
-
Two Ways
Quick Details
-
Port Size:
-
1-1/2 inch
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
2W
-
Brand Name:
-
Acarps
-
Body material:
-
Stainless Steel
-
Voltage:
-
12VDC, 220VAC, , 24VAC, 24VDC
-
Connection type:
-
BSP (G)
-
Working pressure:
-
0-16bar
-
Operation:
-
Three Wire Two Control
-
Temperature:
-
<95℃
-
Running Time:
-
5-15 Seconds
-
Structure Forms:
-
Two Ways
Products Description
Specification:
Medium: Cold/hot water, 60% Ethylene Glycol
Motor Material: Stainless Steel
Body Material: 304 Stainless Steel
Torque：8 N.M
Power Supply: AC220V/DC12V/DC24V/AC24V
Structure Forms: Two Ways
Operation Mode: Three Wire Two Control
Power: 6W (Only when the valves open and close)
Running Time: 5-15 Seconds
Nominal Pressure: 1.6MPa
Medium Temperature: 2°~95°
Maximum Differential Pressure: 1.0MPa
Connection Mode: G Internal Thread
Medium: Cold/hot water, 60% Ethylene Glycol
Motor Material: Stainless Steel
Body Material: 304 Stainless Steel
Torque：8 N.M
Power Supply: AC220V/DC12V/DC24V/AC24V
Structure Forms: Two Ways
Operation Mode: Three Wire Two Control
Power: 6W (Only when the valves open and close)
Running Time: 5-15 Seconds
Nominal Pressure: 1.6MPa
Medium Temperature: 2°~95°
Maximum Differential Pressure: 1.0MPa
Connection Mode: G Internal Thread
