Quick Details
-
Color Print Speed:
-
no
-
Max. Resolution:
-
203 Dots/line
-
Brand Name:
-
Eryin
-
Place of Origin:
-
Fujian, China
-
Maximum roll diameter:
-
50mm
-
Printing Content:
-
multilingual, Numbers, symbols, graphics, curves, ICONS
-
weight:
-
252g
-
Dimension::
-
145*135*70mm (W*D*H)
-
command:
-
compatible with POS/ESC command
-
Printing Method:
-
Thermal Line Printing
-
The battery:
-
2000mAh 8.4v rechargeable lithium battery
-
Power adapter:
-
Ac100-240v wide range input, standard DC 5v-1a adapter
-
Application scenarios:
-
Hotels, gas stations, supermarkets, parking lots, takeaway
Quick Details
-
Interface Type:
-
usb+Wireless
-
Max Paper Size:
-
58mm
-
Black Print Speed:
-
70-90mm/s
-
Color Print Speed:
-
no
-
Max. Resolution:
-
203 Dots/line
-
Brand Name:
-
Eryin
-
Place of Origin:
-
Fujian, China
-
Maximum roll diameter:
-
50mm
-
Printing Content:
-
multilingual, Numbers, symbols, graphics, curves, ICONS
-
weight:
-
252g
-
Dimension::
-
145*135*70mm (W*D*H)
-
command:
-
compatible with POS/ESC command
-
Printing Method:
-
Thermal Line Printing
-
The battery:
-
2000mAh 8.4v rechargeable lithium battery
-
Power adapter:
-
Ac100-240v wide range input, standard DC 5v-1a adapter
-
Application scenarios:
-
Hotels, gas stations, supermarkets, parking lots, takeaway
Product Paramenters
|
Item
|
|
Parameters
|
|
|
Printing
|
Printing Method
|
Thermal dot line printing
|
|
|
|
Resolution
|
203dpi,8dots/mm
|
|
|
|
Printing speed
|
70mm/s
|
|
|
|
Valid printing width
|
48mm
|
|
|
|
Interface
|
Wireless, USB（B-T）
|
|
|
Power saving
|
Sleep mode
|
YES
|
|
|
Character Set
|
Font
|
ASCII:9 17,12 24; Multiple code pages support
|
|
|
Barcode symbologies
|
1D
|
UPC-A,UPC-E,EAN8,EAN13,CODE39,ITF,CODEBAR,CODE128,CODE93
|
|
|
|
2D
|
QR code
|
|
|
Graphics
|
Support bitmap printing with different density and user defined bitmap printing(Max. 40K for per bitmap, and Max. 64K for total)
|
|
|
|
Detection
|
Sensors
|
Paper out detection
|
|
|
LED indicator
|
|
Power Green
|
|
|
|
|
Power Blue
|
|
|
|
|
Feed Yellow
|
|
|
|
|
Feed Red
|
|
|
Charging
|
Charging
|
1)5V/1A in Adapter,
|
|
|
|
|
2)5v/500mA in computer USB connector
|
|
|
|
|
2000mAh/7.4V rechargeable Li-ion battery Full charge can print 100~200m (printing density not more than 12.5%) or
80~100mm(printing density not more than 25%) |
|
|
|
|
|
|
|
|
Recommeded paper
|
FD210.PD150R.PD160R
|
|
|
|
|
|
|
|
|
Paper width
|
58mm
|
|
|
|
|
|
|
|
|
Paper thickness
|
60~80 m
|
|
|
|
|
|
|
|
|
Paper roller diameter
|
50mm
|
|
|
|
|
|
|
|
|
Paper loading
|
Easy loading mechanism
|
|
|
|
|
|
|
|
|
Working condition
|
-10 C~50 C, 20%~85%RH
|
|
|
|
Storage condition
|
-20 C~70 C, 5%~95%RH
|
|
|
|
Dimension
|
120*82*60mm
|
|
|
|
Weight
|
280g(without paper roll)
|
|
|
Reliability
|
TPH
|
50km(not more than 12.5% printing desity)/100 million pulses
|
|
|
Software
|
Emulation
|
ESC/POS compatible command set
|
|
|
|
Driver
|
Windows XP/Win7/Win8/Win10
|
|
