Quick Details
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM50M-36
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
870*665*30mm
-
Fire Safety Class:
-
Class A
-
Cell Type:
-
Mono Solar Cell
-
Solar cell:
-
monocrystalline 47*156.75mm (36pcs)
-
Efficiency:
-
13.53% High Efficiency Solar Panel
-
Junction Box:
-
IP67 Rated
-
Application:
-
Commercial
-
Solar panel:
-
100 Watt Solar Panel
-
Maximum System Voltage:
-
715/1000V
-
OEM Order:
-
Accptable
-
Certificate:
-
CE TUV
Quick Details
-
Type:
-
PERC
-
Panel Efficiency:
-
15.04%
-
Warranty:
-
25 years warranty
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM50M-36
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
870*665*30mm
-
Fire Safety Class:
-
Class A
-
Cell Type:
-
Mono Solar Cell
-
Solar cell:
-
monocrystalline 47*156.75mm (36pcs)
-
Efficiency:
-
13.53% High Efficiency Solar Panel
-
Junction Box:
-
IP67 Rated
-
Application:
-
Commercial
-
Solar panel:
-
100 Watt Solar Panel
-
Maximum System Voltage:
-
715/1000V
-
OEM Order:
-
Accptable
-
Certificate:
-
CE TUV
Product Description
|
Module
|
BSM50M-36
|
|
Maximum Power - Pmax(W)
|
50
|
|
Open Circuit Voltage - Voc(V)
|
22.8
|
|
Short Circuit Current - Isc(A)
|
2.9
|
|
Voltage at Pmax-Vmp(V)
|
18.6
|
|
Current at Pmax-Imp(A)
|
2.69
|
|
Module Efficiency-ηm(%)
|
15.04
|
|
Power Tolerance (W)
|
(0,+3)
|
|
Maximum Series Fuse Rating(A)
|
6~10
|
|
Module
|
BSM100M-36
|
|
Maximum Power - Pmax(W)
|
100
|
|
Open Circuit Voltage - Voc(V)
|
23.4
|
|
Short Circuit Current - Isc(A)
|
5.43
|
|
Voltage at Pmax-Vmp(V)
|
19.4
|
|
Current at Pmax-Imp(A)
|
5.15
|
|
Module Efficiency-ηm(%)
|
17.28
|
|
Power Tolerance (W)
|
(0,+3)
|
|
Maximum Series Fuse Rating(A)
|
10
|
|
Module
|
BSM150M-36
|
|
Maximum Power - Pmax(W)
|
150
|
|
Open Circuit Voltage - Voc(V)
|
23.4
|
|
Short Circuit Current - Isc(A)
|
8.16
|
|
Voltage at Pmax-Vmp(V)
|
19.4
|
|
Current at Pmax-Imp(A)
|
7.73
|
|
Module Efficiency-ηm(%)
|
17.52
|
|
Power Tolerance (W)
|
(0,+3)
|
|
Maximum Series Fuse Rating(A)
|
15
|
Project
|
Packing Information
|
|
|
|
|||
|
Module
|
BSM50M-36
|
BSM100M-36
|
BSM150M-36
|
|||
|
Piled pallet size（20/40’GP）
|
1390*1130*628mm
1565*1130*795mm
|
1390*1130*998mm
1800*1130*795mm
|
1310*1130*800mm
|
|||
|
Gross weight per pallet
|
306 kg/434 kg
|
466 kg
|
310 kg
|
|||
|
Quantity per pallet
|
64 pcs/96 pcs
|
64 pcs
|
30 pcs
|
|||
|
Quantity per 20 feet container
|
1536 pcs
|
1024 pcs
|
480 pcs
|
|||
|
Quantity per 40 feet container
|
4032pcs
|
2304 pcs
|
1530 pcs
|
|||
