- Product Details
- {{item.text}}
Quick Details
-
Color:
-
68.7billion
-
Panel Size:
-
500*500/500*1000
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-LEDRB
-
Brightness:
-
4500-6500, 4500-6500cd/sqm
-
pixel density:
-
65400dot/m²
-
Contrast Ratio:
-
10000:1
-
Color Depth:
-
RGB
-
Lifespan (hours):
-
≥100,000
-
IP Rating:
-
IP65
-
HS Code:
-
8528591090
-
Resolution:
-
65400dot/m²
-
View Angle（H/V）:
-
>160° >160°
-
Keyword:
-
outdoor led display
-
Pixels:
-
P3.91
-
Module size:
-
250*250mm
-
Refresh rate:
-
3840Hz
-
Scanning:
-
1/16S
-
Protection degree:
-
IP65
-
Cabinet material:
-
Die-casting aluminum
-
Weight:
-
7.5kg / Cabinets
-
Installation:
-
Hanging/streching
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
DDW
-
Color:
-
68.7billion
-
Panel Size:
-
500*500/500*1000
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-LEDRB
-
Brightness:
-
4500-6500, 4500-6500cd/sqm
-
pixel density:
-
65400dot/m²
-
Contrast Ratio:
-
10000:1
-
Color Depth:
-
RGB
-
Lifespan (hours):
-
≥100,000
-
IP Rating:
-
IP65
-
HS Code:
-
8528591090
-
Resolution:
-
65400dot/m²
-
View Angle（H/V）:
-
>160° >160°
-
Keyword:
-
outdoor led display
-
Pixels:
-
P3.91
-
Module size:
-
250*250mm
-
Refresh rate:
-
3840Hz
-
Scanning:
-
1/16S
-
Protection degree:
-
IP65
-
Cabinet material:
-
Die-casting aluminum
-
Weight:
-
7.5kg / Cabinets
-
Installation:
-
Hanging/streching
Discover Your Right Application , Make Your Business Possible !
Common warranty in LED field is 2 years, ours is 3 years Longer warranty periods, better after-sale services, worry-free user experience
Project Case
LED displays have been exported to many countries and rigions in the World, and we are highly praised by our customers.
Products Description
Specifications
|
|
P1.95
|
P2.6
|
P2.97
|
P3.91
|
P4.81
|
||||
|
Pixel Pitch
|
1.95mm
|
2.6mm
|
2.97mm
|
3.91mm
|
4.81mm
|
||||
|
Module Size
|
250mmx250mm
|
|
|
|
|
||||
|
lamp Size
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD2020
|
SMD2020
|
||||
|
Module Resolution
|
128*128dots
|
96*96dots
|
84*84dots
|
64*64dots
|
52*52dots
|
||||
|
Viewing Angle (Deg)
|
160
|
|
|
|
|
||||
|
Module Weight
|
0.35Kg
|
|
|
|
|
||||
|
Cabinet Size
|
500*500mm/500*1000mm
|
|
|
|
|
||||
|
Cabinet Resolution
|
256*256dots
|
192*192dots
|
168*168dots
|
128*128dots
|
104*104dots
|
||||
|
Module Quanity
|
4Pcs
|
|
|
|
|
||||
|
Pixel Density
|
262144dots/sqm
|
147456dots/sqm
|
112896dots/sqm
|
65536dots/sqm
|
43264dots/sqm
|
||||
|
Material
|
Die-casting aluminum
|
|
|
|
|
||||
|
Cabinet Weight
|
7.5kg/13kg
|
|
|
|
|
||||
|
Brightness
|
800≤4500cd/㎡
|
|
|
|
|
||||
|
Refresh Rate
|
≥ 3840HZ
|
|
|
|
|
||||
|
Input Voltage
|
AC220V/50Hz or AC110V/60Hz
|
|
|
|
|
||||
|
Power Consumption(Max./Ave.)
|
660/220 W/m²
|
|
|
|
|
||||
|
Installtion Methode
|
Front/Rear
|
|
|
|
|
||||
|
IP Rating(Front/Rear)
|
IP31/IP65
|
|
|
|
|
||||
|
Working Environment:
|
Indoor/Outdoor
|
|
|
|
|
||||
|
Working Temperature (℃)
|
-20~+50℃
|
|
|
|
|
||||
|
Working Humidity (RH)
|
10%~90%
|
|
|
|
|
||||
