Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CNAOM
-
Model Number:
-
LA38-11X/2
-
Product name:
-
Push button Switch
-
Hole size:
-
22MM
-
Mechanical life:
-
More than 500 thousand times
-
Contact:
-
one NO and one NC
-
Function:
-
self reset
-
Certification:
-
CCC
Quick Details
-
Protection Level:
-
A
-
Max. Current:
-
Less than 10A
-
Max. Voltage:
-
440V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CNAOM
-
Model Number:
-
LA38-11X/2
-
Product name:
-
Push button Switch
-
Hole size:
-
22MM
-
Mechanical life:
-
More than 500 thousand times
-
Contact:
-
one NO and one NC
-
Function:
-
self reset
-
Certification:
-
CCC
Product Description
Cnaom high Sensitive contact 22MM Push Button Switches
Push button switch refers to the switch that uses the button to push the transmission mechanism, make the moving contact and the static contact press on or off, and realize the circuit switching.
In the electrical automatic control circuit, it is used to manually send control signals to control contactors, relays, electromagnetic starters, etc.
The Push button switch can complete the start, stop, positive and negative rotation, speed change and interlock and other basic control. Usually each push button switch has two pairs of contacts. Each pair of contacts consists of a normally open contact and a normally closed contact. When the button is pressed, the two pairs of contacts act at the same time, the normally closed contact is disconnected, the normally open contact is closed.
Specification
|
Model
|
LA38-11X/2
|
|
Dimensions of thread openings
|
22MM
|
|
Current
|
Less than 10A
|
|
Contact
|
One NO and One NC
|
|
Contact material
|
Copper
|
|
Voltage
|
440V
|
|
Button type
|
Self-reset
|
|
Product dimensions
|
32*78mm
|
Installation Instructions
Packing & Delivery
|
Packing
|
inner box
|
carton
|
|
|
|
10PCS
|
500PCS
|
|
|
Carton size
|
50.5*33.5*43.5CM 26KGS
|
|
|
|
Delivery
|
<1000
|
>1000
|
|
|
|
within a week
|
It depends on the quantity
|
|
Note:The delivery time is for reference only,please confirm with the seller for details.
