Quick Details
-
Usage:
-
TV
-
Pixels:
-
1920*1080(RGB), FHD
-
Contrast Ratio:
-
4000 : 1 (Typ.)
-
Brightness:
-
0 cd/m² (Typ.)
-
Response Time:
-
8 (Typ.)(G to G) (ms)
-
Best perspective:
-
Full view
-
Support Color:
-
1.07B (8-bit + Dithering)
-
Viewing Angle:
-
89/89/89/89 (Typ.)(CR≥10)
-
Frame Rate:
-
60Hz
Quick Details
-
Type:
-
a-Si TFT-LCD, Open Cell
-
Display Size:
-
48 inch
-
Place of Origin:
-
Guangdong, China
-
Usage:
-
TV
-
Pixels:
-
1920*1080(RGB), FHD
-
Contrast Ratio:
-
4000 : 1 (Typ.)
-
Brightness:
-
0 cd/m² (Typ.)
-
Response Time:
-
8 (Typ.)(G to G) (ms)
-
Best perspective:
-
Full view
-
Support Color:
-
1.07B (8-bit + Dithering)
-
Viewing Angle:
-
89/89/89/89 (Typ.)(CR≥10)
-
Frame Rate:
-
60Hz
Specification
|
Basic Information
|
|
|
|
|
|
|||||
|
Usage:
|
TV
|
|
Type:
|
a-Si TFT-LCD
|
|
|||||
|
Modell:
|
LSC480HN08-8
|
|
Screen Size:
|
48 inch
|
|
|||||
|
Storage Temp.:
|
-20 ~ 65 °C
|
|
Operating Temp.:
|
0 ~ 50 °C
|
|
|||||
|
Frame Rate:
|
60Hz
|
|
Voltage Supply:
|
12.0V (Typ.)
|
|
|||||
|
Pixel Features
|
|
|
|
|
|
|||||
|
Pixel Format:
|
1920×1080(RGB), FHD
|
|
Arrangement:
|
RGB horizontal stripes
|
|
|||||
|
Dot Pitch(mm):
|
0.549×0.183
|
|
Pixel Pitch(mm):
|
0.549×0.549
|
|
|||||
|
Mechanical Size
|
|
|
|
|
|
|||||
|
Active Area(mm):
|
1054.08×592.92
|
|
Outline Dim.(mm):
|
1068.08×608.92
|
|
|||||
|
Depth(mm):
|
1.30 (Typ.)
|
|
|
|
|
|||||
|
Outline Features
|
|
|
|
|
|
|||||
|
Form Style:
|
Flat Rectangle
|
Aspect Ratio:
|
16:9 (H:V)
|
Plate Thickness(mm):
|
0.40+0.50
|
|||||
|
Other Features
|
|
|
|
|
|
|||||
|
Weight:
|
2.80Kgs (Typ.)
|
|
Treatment:
|
Hard coating (2H)
|
|
|||||
|
Basic Information
|
|
|
|
|
|
|||||
|
Luminance(cd/m²):
|
0
|
Contrast Ratio:
|
4000:1 (Typ.)
|
Best Perspective:
|
Full View
|
|||||
|
Viewing Angle:
|
89/89/89/89 (Typ.)(CR≥10)
|
|
Response Time(ms):
|
8 (Typ.)(G to G)
|
|
|||||
|
Color Performance
|
|
|
|
|
|
|||||
|
Color Temperature:
|
7002K
|
|
Display Colors:
|
1.07B (8-bit + Dithering)
|
|
|||||
|
1931
Color Gamlt
|
|
|
|
|
|
|||||
|
NTSC Ratio:
|
67%
|
|
sRGB:
|
81%
|
|
|||||
|
DCI-P3:
|
67%
|
|
Rec.2020:
|
50%
|
|
|||||
|
Adobe RGB:
|
69%
|
|
Remarks:
|
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
|
|
|||||
|
Others
|
|
|
|
|
|
|||||
|
Transmissivity:
|
6.6% (Typ.)
|
|
Single Interface:
|
LVDS (2 ch, 10-bit)
|
|
|||||
