Quick Details
-
Size:
-
6.5*3.5*3m
-
Material:
-
Stainless Steel
-
Warranty:
-
2 years
-
Type:
-
Car Washer
-
Pressure:
-
100 Bar
-
Washing System:
-
high pressure washing
-
Washing Speed:
-
30-40sets/hour
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JD
-
Model Number:
-
S7
-
Size:
-
6.5*3.5*3m
-
Material:
-
Stainless Steel
-
Warranty:
-
2 years
-
Type:
-
Car Washer
-
Pressure:
-
100 Bar
-
Washing System:
-
high pressure washing
-
Washing Speed:
-
30-40sets/hour
Functions:
- High pressure rotating spray rod system
- One channel intelligent chemical liquid ratio system
- Non spot flushing system
- Intelligent three dimensional detection system
- Fault alarm system
- Smooth suspension host system
- Fully intelligent PLC central control system
|
Technical parameters |
Control system |
||
|
Installation dimensions |
6.5m*3.5m*3m |
PLC |
Delta |
|
Track length |
6.5m |
The inverter |
Delta |
|
Maximum wash size |
5.5m*2.1*2.1m |
The sensor |
Bi DUK |
|
The water pressure |
80kg |
|
|
|
The power supply |
380v/50Hz |
|
|
|
The host power |
7.5kw |
|
|
|
Comprehensive configuration |
The transmission system |
||
|
Chassis wash |
√ |
Driving longitudinally |
Belt drive |
|
Diy maintenance |
Free maintenance |
Horizontal drive |
NO |
|
Numerical control system |
NO |
The drive motor |
Asynchronous motor |
|
Credit card system |
optional |
Detection system |
ultrasonic |
|
Bubble function |
ratio of automatic |
|
|
|
Wash the car counting |
√ |
|
|
|
Breakdown self check |
√ |
|
|
|
Function of water wax |
√ |
|
|
|
LED lights hint |
√ |
|
|
|
fan |
FOUR |
|
|
1. High pressure pre-wash for under chassis and wheels.
Equipped with a unique chassis and fan hub flush function, 80bar high pressure water can effectively remove dirt on chassis, body sides and wheels.
2.Smart 360 rotate arm, Flush car body 360° with high pressure water.
Complete 360° rotating within 30 seconds, water saving 50%, electricity saving 60%, automatic detect the length and width of the vehicle, up to 80bar high pressure water can easily remove the dirt.
3.Smart 360 rotate arm, spray various washing chemicals with high-precision proportioning technology.
100% accurate measurement with adjustable ratio. only 20~50ml pre-soak comsumption for washing one car through high precision chemical mixing system, save material and cost efficiently.
