Famous brand static compactor road roller SRT26H-C6 26ton compactor with good quality

FOB Reference Price: Get Latest Price

≥1 Sets

US $45888

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Engine Brand:: Imported

Travel Speed:: 7.3km/h

Place of Origin:: Shandong, China

Dimension(L*W*H):: 4920*2915*3410mm

Drum diameter:: /

Exciting Force:: /

Marketing Type:: New Product

Quick Details

Type:: Other

Power:: 92kw

Weight:: 26TON

Engine Brand:: Imported

Travel Speed:: 7.3km/h

Place of Origin:: Shandong, China

Dimension(L*W*H):: 4920*2915*3410mm

Drum diameter:: /

Exciting Force:: /

Marketing Type:: New Product

Hot Product Links

Product Description

Configuration Selling Point

The Weichai WP4 engine for the roller developed by the Group matches well with Linde high-pressure heavy-duty closed-circuit

vibration hydraulic system for fuel saving, high efficiency and large excitation force so that it can easily cope with heavy-load working

conditions, with small fluctuations and rapid vibration start; Shantui patented vibrating drum is of “three-in-one” design to improve the

compaction flatness;

Ease Of Maintenance And Operation Comfort

The large space cab of new appearance without A-pillar guarantees unobstructed vision and comfortable operation; the engine and

gearbox are inverted for easy maintenance; the filter elements are centrally arranged, and the oil drain of the engine and the water

outlet of the water tank are led outward for easy maintenance;

Adaptability To Diverse Working Conditions

It is suitable for the compaction of the base course and sub-base course of large-scale projects such as highways, railways and

airports, and can compact the non-adhesive materials and semi-adhesive materials such as sand, gravel, crushed stone, rock fill, etc.

It can be equipped with optional lugs, with a variety of functions, which is suitable for clay and other working conditions

Main Parameter

Parameter name	SRT26H-C6
Performance parameters
Operating weight (Kg)	26000
Ground pressure (KPa)	200-460
Gradeability (%)	22%
Engine
Engine model	WP4.6N
Overall dimensions
Overall dimensions of machine (mm)	492029153410
Driving performance
Forward speed (km/h)	0-6,0-13
Reversing speed (km/h)	0-6,0-13
Chassis System
Tank capacity
Working device
Compacting width(mm)	2750

Our Factory

RISEN ConstructionMachinery (Shanghai) Co., Ltd is engaged in developing, manufacturing andexporting construction machines in the areas of building, mining, energy andlogistic engineering. Offering 8 major categories, 38 product line and morethan 1000 models, RISEN is able to provide complete equipment package to theclients from all walks of life.We are a wholesaler of many brands in China, a professional exporter of construction machinery and a one-stop solution provider. Our team has over 15 years of experience in this field.

From the factory to our customer's destination, we will conduct all-round supervision .We can also helpto sign purchase ordercontracts , test product quality , guarantee timely delivery , and accomodate special orders .

What is the proportion of your products exported?

75% of our products are exported to all over the world.

What is the payment term?

Payment term is negotiable and there will be favorable payment terms for long-term customers. TT, L/C, D/P, depending on the cooperation time, country and contract value.

What kind of logistic service do you supply?

A. Transportation: railway transportation, international through transport, including (international railway through transportation, Sea-rail intermodal through transportation, sea-land multimodal transportation. Means of transport : Container, LCL, FRC, ro-ro, bulk cargo, train carriage, truck, air plane.

B. Term: FOB,CIF, DAP, to door service, etc.
