Quick Details
-
Brand Name:
-
Sun Glory
-
Dimension(L*W*H):
-
1950*2100*3700mm
-
Weight (T):
-
8.5 T
-
Model Number:
-
YZ28G-120
-
Motor Power (kw):
-
30 kw
-
CNC or Not:
-
Normal
-
Power Source:
-
Hydraulic
-
Power:
-
30KW
-
Voltage:
-
380V/220V Optional
-
Local Service Location:
-
India
Quick Details
-
Machine Type:
-
Four-column Two-beam Hydraulic Press
-
Return Force (kN):
-
140 kN
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sun Glory
-
Dimension(L*W*H):
-
1950*2100*3700mm
-
Weight (T):
-
8.5 T
-
Model Number:
-
YZ28G-120
-
Motor Power (kw):
-
30 kw
-
CNC or Not:
-
Normal
-
Power Source:
-
Hydraulic
-
Power:
-
30KW
-
Voltage:
-
380V/220V Optional
-
Local Service Location:
-
India
Specification
|
Item
|
|
Unit
|
YZ28G-200
|
YZ28G-250
|
YZ28G-300
|
YZ28G-350
|
|
|
Main cylinder force
|
|
KN
|
1500
|
1500
|
2000
|
2500
|
|
|
Rating working pressure of hydraulic system
|
|
MPA
|
21
|
21
|
25
|
21
|
|
|
Return force
|
|
KN
|
140/110
|
140/110
|
180-125
|
180
|
|
|
Cushion force
|
|
KN
|
500
|
1000
|
1000
|
1000
|
|
|
Max. working pressure of cushion cylinder
|
|
MPA
|
20
|
26
|
26
|
26
|
|
|
Ejector force
|
|
KN
|
30
|
30
|
30
|
30
|
|
|
Max. stroke of cushion cylinder
|
|
MM
|
300
|
300
|
300
|
300
|
|
|
Max. stroke of ejector
|
|
MM
|
200
|
200
|
200
|
200
|
|
|
Max. stroke of slider table
|
|
MM
|
550
|
550
|
550
|
600
|
|
|
Open height
|
Max.
|
MM
|
950
|
950
|
1000
|
1110
|
|
|
|
Min
|
MM
|
400
|
400
|
450
|
510
|
|
|
Slide speed
|
Down
|
MM/S
|
250
|
250
|
330
|
245
|
|
|
|
Pressure
|
MM/S
|
25
|
25
|
20~29
|
(13)19/33
|
|
|
|
Up
|
MM/S
|
255
|
255
|
290
|
250
|
|
|
Cushion speed
|
Up
|
MM/S
|
115
|
85
|
95
|
100
|
|
|
|
Down
|
MM/S
|
down with
slide table |
down with
slide table |
down with
slide table |
down with
slide table |
|
|
Power of motor
|
|
KW
|
30
|
30
|
37
|
37
|
|
|
Dimension of working table(LR*FB)
|
|
MM2
|
700*880
|
700*880
|
750*900
|
800*990
|
|
|
Dimention of machine(LR*FR*H)
|
|
MM2
|
1950*2100*3700
|
1950*2100*3700
|
2250*2350*4100
|
2100*2400*4200
|
|
Product Description
For You，We Can Set Up A Full Line Of
Nonstick Cookware
，
Aluminum Pot Pan
，
Tempered Glass Pot Lid
etc.
We
Guarantee
Your Production
Success Rate＞97.5%
.
Project We Have Done
We Already Set Up
20+ Production Line
For Our Clients.
In
India
，
Bangladesh
，
Saudi Arab
，
Turkey
，
Vietnam
，
Peru
，
Algeria
...
Why Choose us
In 35 Countries，We Have Six
Overseas Engineer Team
Can Go To Your Factory Within
24 Hour
.
We Provide
Equipment
Installation
&
Maintaining
，
Worker
Training
.
Packing & Delivery
