Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Unionwell
-
Model Number:
-
G307-150PA00U
-
Product name:
-
Waterproof Micro Switch for Automotive Switch Application
-
Electrical life:
-
50,000cycles
-
Mechanical life:
-
1,000,000cycles
-
Function/circuit:
-
SPDT (or SPST-NO, NC for option)
-
Lever type:
-
Straight lever
-
Operating force:
-
50gf max w/ lever (light or heavy for option)
-
Company assurance system:
-
ISO9001 & TS16949
-
Environmental compliance:
-
RoHS, Reach
-
Terminal type:
-
Solder terminals (other types for option)
-
Certification:
-
ENEC,ISO,CQC,RoHS, REACH
Quick Details
-
Protection Level:
-
IP67
-
Max. Current:
-
10A, 15A
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Unionwell
-
Model Number:
-
G307-150PA00U
-
Product name:
-
Waterproof Micro Switch for Automotive Switch Application
-
Electrical life:
-
50,000cycles
-
Mechanical life:
-
1,000,000cycles
-
Function/circuit:
-
SPDT (or SPST-NO, NC for option)
-
Lever type:
-
Straight lever
-
Operating force:
-
50gf max w/ lever (light or heavy for option)
-
Company assurance system:
-
ISO9001 & TS16949
-
Environmental compliance:
-
RoHS, Reach
-
Terminal type:
-
Solder terminals (other types for option)
-
Certification:
-
ENEC,ISO,CQC,RoHS, REACH
Feature
-Designed for water and dust tight(IP67)
-Small compact size
-Global safety approvals
-Long life and high reliability
-Variety of levers
-Wide range of wiring terminals
-Widely used in Automotive Electronics, Appliance and Industrial Control etc.
-Customized designs
-Designed for water and dust tight(IP67)
-Small compact size
-Global safety approvals
-Long life and high reliability
-Variety of levers
-Wide range of wiring terminals
-Widely used in Automotive Electronics, Appliance and Industrial Control etc.
-Customized designs
Rating：
0.1A /125VAC; 3A/ 12VDC ; 0.1A /250VAC; 0.1A/ 48VDC u 1E5.
Operating
FrequencyElectrical: 0.1A-120/3A-10~30 cycles/minute
Operating Frequency
Mechanical:
120 cycles/minute
Contact Resistance(Initiative):
100mΩ Max
Insulation Resistance(at 500VDC):
100MΩ Min
Vibration durability:
10~55Hz, move 0.75mm(p-p)
Dielectric Strength：
500VAC (50~60Hz)
Storage Temperature：
-40℃-+85℃
Storage Humidity：
85% RH Max
Service Life
Electrical：
6,000~500,000/cycles(Depend on part number)
Service
Mechanical：
Min.500,000/cycles
