Quick Details
-
Application:
-
General Purpose
-
Package / Case:
-
Through Hole
-
Description:
-
/
-
Capacitance:
-
0.01uF~4.7uF
-
Features1:
-
Non inductive and self-healing
-
Features2:
-
Low DF and high IR
-
Features3:
-
High stability of capacitance & DF versus temperature & frequency
-
Features4:
-
Very small inherent temperature rise
-
Other:
-
MPP Film Capacitor
-
Type:
-
Polypropylene Film Capacitor
-
Media Available:
-
datasheet/Photo
-
Operating Temperature:
-
-40℃~+105℃
-
Tolerance:
-
J(+/-5%); K(+/-10%)
-
Rated Voltage:
-
250, 400, 630VDC
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
CT
-
Model Number:
-
MPP(CBB21)
-
Application:
-
General Purpose
-
Package / Case:
-
Through Hole
-
Description:
-
/
-
Capacitance:
-
0.01uF~4.7uF
-
Features1:
-
Non inductive and self-healing
-
Features2:
-
Low DF and high IR
-
Features3:
-
High stability of capacitance & DF versus temperature & frequency
-
Features4:
-
Very small inherent temperature rise
-
Other:
-
MPP Film Capacitor
-
Type:
-
Polypropylene Film Capacitor
-
Media Available:
-
datasheet/Photo
-
Operating Temperature:
-
-40℃~+105℃
-
Tolerance:
-
J(+/-5%); K(+/-10%)
-
Rated Voltage:
-
250, 400, 630VDC
High stability capacitance MPP film capacitor 0.01uF ~ 3.3uF 250VDC, 400VDC, 630VDC
METALLIZED POLYPROPYLENE FILM CAPACITOR (COATING)
|
TYP E : MPP |
|
|
FEATURES |
APPLICATIONS |
|
|
|
|
|
|
|
SPECIFICATIONS |
|
|
Dielectric |
Polypropylene film |
|
Electrodes |
Vacuum evaporated metal |
|
Coating |
Epoxy resin coating |
|
Leads |
Radial leads of tinned wire |
|
Climatic Catalogue |
40 / 85 / 21 |
|
Capacitance versus Rated Voltage (U R ) |
250VDC 0.01uF ~ 3.3uF ; 400VDC 0.01uF ~ 1.5uF 630VDC 0.01uF ~ 0.68uF; |
|
Capacitance Tolerance |
J = ± 5% K = ±10% M = ± 20% |
|
Dissipation Factor (Tangent of Loss) |
DF<=0.10% (at 20℃,1KHZ) |
|
Voltage Proof |
1.6×U R (1minute at20℃) |
|
Insulation Resistance |
C<=0.1uF IR>=30,000MΩ C>0.1uF IR×C>=3,000MΩ / uF (1minute at20℃and RH<=65%) |
