15 inch pa subwoofer for sound box, 15" subwoofer 500 watt speaker

FOB Reference Price: Get Latest Price

≥1 Pieces

US $5

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Product Name:: 15 inch pa subwoofer

Nominal Diameter:: 395mm (15 in)

Nominal lmpedance:: 8Ω

AES Power Handing:: 500W

Sensitivity:: 97dB

Frequency Range:: 30-1600Hz

Magnet Size:: 220mm

Voice Coil Diameter:: 100mm(4in)

Power:: 500W

Frequency Range (Hz):: 30-1600Hz

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: Merry Audio

Model Number:: MR15G401

Product Name:: 15 inch pa subwoofer

Nominal Diameter:: 395mm (15 in)

Nominal lmpedance:: 8Ω

AES Power Handing:: 500W

Sensitivity:: 97dB

Frequency Range:: 30-1600Hz

Magnet Size:: 220mm

Voice Coil Diameter:: 100mm(4in)

Power:: 500W

Frequency Range (Hz):: 30-1600Hz

Product Description

15 inch pa subwoofer for sound box, 15" subwoofer 500 watt speaker

1- 4" very large format voice coil;

2- Ferrite Magnetics

3- Die Cast Aluminum frame;

4- 1000 Watts peak power handling;

MR15G401

15"-500W-97dB

NOMINAL SPECIFICATIONS

Nominal Diameter 395mm (15 in)

Overall Diameter 395mm(15 in)

Bolt circle diameter 373mm

Baffle Cutout Diameter 355mm

Depth 165mm

Net Weight 10.5kg

Shipping Box 420×420×180mm

Shipping Weight 11kg

TECHNICAL PARAMETERS

Nominal lmpedance 8Ω

Minimum lmpedance 6.6Ω

AES Power Handing(1) 500W

Maximum Power Handling(4) 1000W

Sensitivity(1W/1m) 97dB

Frequency Range 30-1600Hz

Voice Coil Diameter 100mm(4in)

Winding Material CU

Former Material Glass Fiber

Winding Depth 23mm

Magnetic Gap Depth 12mm

Flux Density 1.15T

Magnet Ferriter Ring

Demodulation NO

Suspension(5) Triple Roll

THIELE & SMALL PARAMETERS

Fs 36Hz

Re 4.9Ω

Qes 0.27

Qms 6.2

Qts 0.26

Vas 155 dm³

Sd 881cm²

Xmax 8.5mm

Mms 150g

Bl 24.5N/A

Cms 0.083mm /N

η(Eta Zero) 3.2%

EBP 133Hz

speaker pictire
