Quick Details
-
Brand Name:
-
PHIYANG
-
Material:
-
CARTON case, Stainless Steel 304 or 316
-
Weight:
-
13kg
-
Size:
-
109*27*49cm
-
Weight (KG):
-
13 kg
-
Model:
-
PHYC-320
-
Power:
-
320W
-
Wavelength:
-
253.7nm
-
Lamp Related Life:
-
6000hrs
-
FLOW RATE:
-
25-30T
-
Diameter of flange:
-
DN20/DN25/DN32/DN40/DN50/DN65
-
Quantity of uv:
-
4*80W
-
MOQ:
-
1 Set
Quick Details
-
Marketing Type:
-
New Product 2021
-
Core Components:
-
ballast
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
PHIYANG
-
Material:
-
CARTON case, Stainless Steel 304 or 316
-
Weight:
-
13kg
-
Size:
-
109*27*49cm
-
Weight (KG):
-
13 kg
-
Model:
-
PHYC-320
-
Power:
-
320W
-
Wavelength:
-
253.7nm
-
Lamp Related Life:
-
6000hrs
-
FLOW RATE:
-
25-30T
-
Diameter of flange:
-
DN20/DN25/DN32/DN40/DN50/DN65
-
Quantity of uv:
-
4*80W
-
MOQ:
-
1 Set
Product Description
S
t
erilization efficiency up to 99.99%
No secondary pollution, no by-productsEasy to install
Easy maintenance
Maximum working water pressure: 8 bar(116psi)
Optimumambient temperature:2-40C
Shell material: stainless steel 304,316(Optional)
ron<0.3ppm(0.3mgL)
Hardness <7gpg(120mg/L)
Turbidity <1NTU
UVpenetration>75%
The lamp can be made in China or imported Philips
Maximum working water pressure: 8 bar(116psi)
Flange and thread sizes can be customized.
OEM/ODM Stainless Steel UV
253.7nm
Water Purifier UV Sterilizer(4W TO
3000W
)
FAQ
What contaminants does a UV water system remove?
There are many advantages to dealing with microbial contaminants such as bacteria (including coliform and E. coli), viruses, molds, algae, yeasts, and oocysts such as cryptosporidium and flagellates.
There are many advantages to dealing with microbial contaminants such as bacteria (including coliform and E. coli), viruses, molds, algae, yeasts, and oocysts such as cryptosporidium and flagellates.
What are the primary benefits of ultraviolet water treatment?
Ultraviolet (UV) light treatment is a widely recognized and proven method of disinfection of water. It is a physical treatment,not chemical, so it doesn't alter the water chemistry. UV adds nothing to the water such as undesirable color, odor, taste or flavor and neither does it generate harmful by-products.
Simple installation and mainte- nance.compact unit reauires minimum space.
Fast:Water is ready for use as soon as it leaves the sterilizer-no further contact time required.
Chemical free：No chlorine taste or corrosion problems.
Safe:No danger of overdosing .no addition of chemicals.
Ultraviolet (UV) light treatment is a widely recognized and proven method of disinfection of water. It is a physical treatment,not chemical, so it doesn't alter the water chemistry. UV adds nothing to the water such as undesirable color, odor, taste or flavor and neither does it generate harmful by-products.
Simple installation and mainte- nance.compact unit reauires minimum space.
Fast:Water is ready for use as soon as it leaves the sterilizer-no further contact time required.
Chemical free：No chlorine taste or corrosion problems.
Safe:No danger of overdosing .no addition of chemicals.
What industries use UV water treatment?
It is a well-proven technology and pretty much every industry that utilizes water for process or production could employ UV
technology for water treatment. Examples include microelectronics, life sciences, food & beverage, recreational water, drinking water, etc.
It is a well-proven technology and pretty much every industry that utilizes water for process or production could employ UV
technology for water treatment. Examples include microelectronics, life sciences, food & beverage, recreational water, drinking water, etc.
Specification
|
Product Model
|
Power
|
Quantity of UV lamps
|
Specification
Inlet/Outlet
|
Flow Rate
|
Diameter of flange
|
|
PHYC-080
|
80w
|
1*80w
|
900*89mm
|
3-6T
|
DN20/DN25/DN32/DN40/DN50/DN65
|
|
PHYC-160
|
160w
|
2*80w
|
900*108mm
|
10-15T
|
DN25/DN32/DN40/DN50/DN65/DN80
|
|
PHYC-240
|
240w
|
3*80w
|
900*133mm
|
20-22T
|
DN40/DN50/DN65/DN80/DN100
|
|
PHYC-320
|
320w
|
4*80w
|
900*133mm
|
25-30T
|
DN40/DN50/DN65/DN80/DN100
|
|
PHYC-400
|
400w
|
5*80w
|
900*168mm
|
35-37T
|
DN50/DN65/DN80/DN100/DN125
|
|
PHYC-480
|
480w
|
6*80w
|
900*219mm
|
40-45T
|
DN65/DN80/DN100/DN125/DN150
|
|
PHYC-560
|
560w
|
7*80w
|
900*219mm
|
50-52T
|
DN65/DN80/DN100/DN125/DN150
|
|
PHYC-640
|
640w
|
8*80w
|
900*219mm
|
55-60T
|
DN65/DN80/DN100/DN125/DN150
|
|
PHYC-720
|
720w
|
9*80w
|
900*273mm
|
65-67T
|
DN80/DN100/DN125/DN150/DN200
|
|
PHYC-800
|
800w
|
10*80w
|
900*273mm
|
70-75T
|
DN80/DN100/DN125/DN150/DN200
|
|
PHYC-120
|
120W
|
1*120W
|
1200*89mm
|
8T
|
DN20/DN25/DN32/DN40/DN50/DN65
|
|
PHYC-240
|
240W
|
2*120W
|
1200*108mm
|
20T
|
DN25/DN32/DN40/DN50/DN65/DN80
|
|
PHYC-360
|
360w
|
3*120w
|
1200*133mm
|
35-36T
|
DN40/DN50/DN65/DN80/DN100
|
|
PHYC-480
|
480w
|
4*120w
|
1200*133mm
|
45-48T
|
DN40/DN50/DN65/DN80/DN100
|
|
PHYC-600
|
600w
|
5*120w
|
1200*168mm
|
55-60T
|
DN50/DN65/DN80/DN100/DN125
|
|
PHYC-720
|
720w
|
6*120w
|
1200*219mm
|
70-72T
|
DN65/DN80/DN100/DN125/DN150
|
|
PHYC-840
|
840w
|
7*120w
|
1200*219mm
|
80-84T
|
DN65/DN80/DN100/DN125/DN150
|
|
PHYC-960
|
960w
|
8*120w
|
1200*219mm
|
95-96T
|
DN65/DN80/DN100/DN125/DN150
|
|
PHYC-1080
|
1080w
|
9*120w
|
1200*273mm
|
100-108T
|
DN80/DN100/DN125/DN150/DN200
|
|
PHYC-1200
|
1200w
|
10*120w
|
1200*273mm
|
115-120T
|
DN80/DN100/DN125/DN150/DN200
|
|
PHYC-1320
|
1320w
|
11*120w
|
1200*273mm
|
130-132T
|
DN80/DN100/DN125/DN150/DN200
|
|
PHYC-1440
|
1440w
|
12*120w
|
1200*273mm
|
140-144T
|
DN80/DN100/DN125/DN150/DN200
|
