The VSI is typically used after a primary or secondary crusher. This makes a VSI ideal for making sand and for making coarse and medium aggregates for concrete/asphalt production.
- Product Details
- {{item.text}}
Quick Details
-
Power:
-
440-520
-
Dimension(L*W*H):
-
5100x2790x3320
-
Weight:
-
27500 kg
-
Name:
-
Small kaolin gravel sand making machine for quarry price
-
Soft material max feeding size (mm):
-
<50
-
Hard material max feeding size (mm):
-
<45
-
Rotary speed (r/min):
-
1180-1280
-
Processed Materials:
-
Ore,Granite,Basalt,Quartz,Pebbles
-
Vibrating sensor inspection scope:
-
0.1-20mm/s
-
Keyword:
-
VSI crusher
-
Color:
-
Customizable
-
Installation:
-
Engineer Guide
-
Power of double oil pump:
-
2x0.31kw
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
SHIBO
-
Voltage:
-
380V:50HZ
-
Power:
-
440-520
-
Dimension(L*W*H):
-
5100x2790x3320
-
Weight:
-
27500 kg
-
Name:
-
Small kaolin gravel sand making machine for quarry price
-
Soft material max feeding size (mm):
-
<50
-
Hard material max feeding size (mm):
-
<45
-
Rotary speed (r/min):
-
1180-1280
-
Processed Materials:
-
Ore,Granite,Basalt,Quartz,Pebbles
-
Vibrating sensor inspection scope:
-
0.1-20mm/s
-
Keyword:
-
VSI crusher
-
Color:
-
Customizable
-
Installation:
-
Engineer Guide
-
Power of double oil pump:
-
2x0.31kw
Product Description
|
Model
|
|
VSI-7611
|
VSI-8518
|
VSI-9526
|
VSI-1140
|
||||
|
Capacity(t/h)
|
Cascade and Center Feeding
|
120-180
|
200-260
|
300-380
|
450-520
|
||||
|
|
Center Feeding
|
60-90
|
100-130
|
150-190
|
225-260
|
||||
|
Feeder Opening Size (mm)
|
Soft Material
|
≤35
|
≤40
|
≤45
|
≤50
|
||||
|
|
Hard Material
|
≤30
|
≤35
|
≤40
|
≤45
|
||||
|
Rotation Speed
|
|
1700-1890
|
1520-1690
|
1360-1510
|
1180-1310
|
||||
|
Power of the Double Motors(kw)
|
|
110-150
|
180-220
|
264-320
|
400-440
|
||||
|
Overall Dimension(mm)
|
|
3700x2150x2100
|
4140x2280x2425
|
4560x2447x2778
|
5000X2700X3300
|
||||
|
Weight (t)
|
|
7.8
|
10.3
|
16
|
25.6
|
||||
|
Power
|
|
380V:50Hz
|
|
|
|
||||
|
Vibrating Sensor
|
|
Inspection Scope: 0.1-20mm/s,it can be adjusted continuously
|
|
|
|
||||
|
Thin oil lubrication station
|
Power of Double Oil Pump
|
2×0.31kw
|
|
|
|
||||
|
|
Safety
|
supply of oil; Stop automatically without oil flow or oil pressure; Water cooled; Heating start the motor in winter
|
|
|
|
||||
|
|
Overall Dimension (mm)
|
820×520×1270
|
|
|
|
||||
|
|
Power of Oil-box HeaterDimension (kw)
|
2KW
|
|
|
|
||||
Advantages of
VSI Sand Making Machine Sand Crusher
1.Large handing capacity and high output.
2.Low wearing parts cost.
3.Perfect product shape.
4.Hydraulic devices are maintained easily.
5.Thinning oil lubricant and automatic.
6.Multi-functions and Flexible application.
2.Low wearing parts cost.
3.Perfect product shape.
4.Hydraulic devices are maintained easily.
5.Thinning oil lubricant and automatic.
6.Multi-functions and Flexible application.
Project Case
The sand making machine is the third stage of crushing plant.
A VSI sand making machine is ideal for making sand and for making coarse and medium aggregates for concrete/asphalt production.
The sand making machine can also be movable if your site space is limited , we produce two kinds of mobile crusher: wheel type and crawler type.
Sand Making Plant
Details Images
VSI Sand Making Machine
Sand washing machine
Sand washer is the commonly used equipment in artificial sand making production line. It is widely used to process silica sand, river sand, yellow sand, sea sand, etc. It is used to remove the dirt and impurities in sand for sand washing, classifying and grading to meet the standard.
Vibrating screen
Sand screening machine is widely used to classify the minerals such as stone,sand, ore and othe kinds of minerals in mining, quarry, construction, building material industry. It can be featured with 2 layers, 3 layers, 4 layers. It is used to sort and classify the materials accoding to the particle size by its circular vibration.
Packing and delivery
The main machine is nude packing, motor, v-belt, Lubrication system and other small parts are packing in wooden box.
