Quick Details
Quick Details
-
Material:
-
Zirconia Ceramic
-
Place of Origin:
-
Shanghai, China
Features:
- Use temperatures up to 2400°C
- High density
- Low thermal conductivity (20% that of alumina)
- Chemical inertness
- Resistance to molten metals
- Ionic electrical conduction
- Wear resistance
- High fracture toughness
- High hardness
| Performance | |||
| Item | Unit | Zirconia | |
| Physical Characteristics | Bulk density | g/cm 3 | 6.05 |
| Water absorption | % | 0 | |
| Mechanical Characteristics |
Flexural strength |
Mpa | 1000 |
| Hardness Vickers | Gpa | 89 | |
| Elastic modulus | Gpa | 200 | |
| Poisson’s ratio | - | 0.31 | |
| Thermal Characteristics | Linear expansion coefficient | (20-500 0 C) 10 -6 / 0 C | 10 |
| Thermal conductivity | w/(m.k) | 2.5 | |
| Specific Heat | *10 -3 J/(kg*K) | 0.5 | |
| Electrical Characteristics | Dielectric constant (1MHZ) | - | N.A. |
| Dielectric loss angle | *10 -4 | N.A. | |
| Dielectric strength | *10 6 V/m | N.A. | |
| Processing technology | |||
| Process range (mm) | |||
| Outside Diameter | 1---300 | ||
| Inside Diameter | 0.5---300 | ||
| Length | 0.5---600 | ||
| Accuracy of working (mm) | |||
| Perpendicularity | 0.001 | ||
| Concentricity | 0.001 | ||
| Roundness | 0.0005 | ||
| Straightness | 0.005 | ||
| Parallelism | 0.01 | ||
| Planeness | 0.005 | ||
| Roughness | 0.005 | ||
| Fit clearance | 0.005 | ||
