The automatic pressure overflow filling machine is suitable to fill all kinds water based liquid in food and drinking industry, like wine, milk, liquor, vinegar, juice, mineral water etc...
keep in the consistent visual fill level.
- Product Details
- {{item.text}}
Quick Details
-
Filling Accuracy:
-
05%-1%
-
Voltage:
-
220V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JERRY PACK
-
Dimension(L*W*H):
-
2000*1000*1700
-
Weight:
-
400 KG
-
Function:
-
Automatic Filler
-
Filling nozzles:
-
12 Nozzles
-
Bottle type:
-
PET Plastic Bottle Glass Bottle
-
Advantage:
-
Same liquid visual level
Quick Details
-
Machinery Capacity:
-
4000BPH, 8000BPH, 6000BPH, 2000BPH, 1000BPH
-
Packaging Material:
-
Plastic, Glass
-
Filling Material:
-
Beer, Milk, Water, Oil, Juice, Other
-
Filling Accuracy:
-
05%-1%
-
Voltage:
-
220V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JERRY PACK
-
Dimension(L*W*H):
-
2000*1000*1700
-
Weight:
-
400 KG
-
Function:
-
Automatic Filler
-
Filling nozzles:
-
12 Nozzles
-
Bottle type:
-
PET Plastic Bottle Glass Bottle
-
Advantage:
-
Same liquid visual level
Products Description
Equipment Description：
Product Application
Product Features
The desired product to be filled is held in a stainless steel reservoir, then pumped into a manifold to disperse product to each of your filling nozzles. Once the product reaches your desired cosmetic fill level in each bottle, excess product or foam overflows back to the reservoir. Advantages of the Overflow Filler include even fill levels,variable pressure pump speed control (to reduce foam), and ease of operation.
In the same filling level:
Automatic Pressure Overflow Filler is typically used in consumer packaging applications where a
consistent visual
(spirits,wine,or cosmetic)
fill level
is required.
Filling system
In the picture is the
8-heads
filling machine.
The speed is about
2000 BPH
based on 750 ml.
Can customize different
(2/4/6/8/12/16)
heads according to different requirements .
Controlling system
The automatic pressure overflow filling machine adopts full-auto PLC + human-computer touch screen control system.
For different volume for example, 500ml, 1000ml, 2000ml, we set three procedures, mode 1, mode 2, model 3``` The PLC can save these parameters for later use.
Operators do not need too much complicated adjustments; the filling machine can switch between the three models easily.
Machine component
All the contacted part with the liquid is made by Stainless steel 316L. Other parts are made by stainless steel 304.
Use world word-class brand components:
Photo sensor---Sick (Germany) ;
PLC---Mitsubishi (Japan);
Electrinic control part--- Mitsubishi (Japan);
Touch screen---Kinco (Shanghai) ;
Cylinder--AirTAC (Taiwan)
Technical parameters
|
Voltage
|
220 volts,single phase, 60/50 Hz
|
|
Filling range
|
100ml-5000ml
|
|
Filling accuracy
|
0.5%-1%
|
|
Air source pressure
|
0.6-0.8 MPa
|
|
Filling heads
|
2/4/6/8/10/12/16 (can be customized)
|
|
Filling speed
|
2000 BPH ( based on 8 heads, 750 ml )
|
