Basic Parameters
|
|
|
|
Maximum wheelbase
|
1800mm
|
|
|
Spread size
|
2090*1826*810mm
|
|
|
Folded size
|
1000*1000*900mm
|
|
|
Wingspan diameter
|
2650mm
|
|
|
Battery
|
14S 28000mAh
|
|
|
Flight Parameters
|
|
|
|
Hover
|
＞20 min(no load)
|
|
|
|
＞10min(full load)
|
|
|
Flying speed
|
3-8m/s
|
|
|
Maximum flight speed
|
8m/s
|
|
|
Work height
|
1-50m
|
|
|
Obstacle avoidance detection distance
|
1～40 m
( Forward or backward detection depending on the flight direction)
|
|
|
Obstacle avoidance perception range
|
3m
obstacle diameter>=2.5cm
|
|
|
Spray Parameters
|
|
|
|
Spray water pressure
|
0-400Bar
|
|
|
Pump intensity of pressure
|
0-5800 PSI
|
|
