Quick Details
-
Dimension(L*W*H):
-
3200*2400*2500
-
Weight:
-
1500
-
Name:
-
motorcycle tire retreading machine
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
control system:
-
automatic
-
heating way:
-
electric
-
vulcanizing way:
-
hot air
-
usage:
-
rubber vulcanizing
-
using life:
-
more than 15 years
-
Certification:
-
ISO CE SG.S
-
Marketing Type:
-
New Product 2025
-
Advantage:
-
High Producing Efficiency
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Guangyue
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
3200*2400*2500
-
Weight:
-
1500
-
Name:
-
motorcycle tire retreading machine
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
control system:
-
automatic
-
heating way:
-
electric
-
vulcanizing way:
-
hot air
-
usage:
-
rubber vulcanizing
-
using life:
-
more than 15 years
-
Certification:
-
ISO CE SG.S
-
Marketing Type:
-
New Product 2025
-
Advantage:
-
High Producing Efficiency
Motorcycle tire buffing maching for tire retreading plant
Brief Introduction of the machine:
1.This curing chamber is also called Vulcanizing Machine or Vulcanizng Tank
2.Ii is used in cold tire retreading process
3.This machine has three heat ways:oil,Steam and electric.
Show of some products:
Advantages:
1.Easy handling and Safety
2.Advantage design
3.Full automatic controll
4.Average heat and good heat distribution
5.Durable and reliable
6.tire recycling machine , tire retreading machinery
Functions:
1.To make prcured tread bonded firmly together with old tire .Automatic temperature-controlled ,automatic pressure relief once exceeding the pressure set .
2.Multiple safety interlock to guarantee safe operation
Main Parameters:
|
Item |
800 |
1200 |
1500 |
1700 |
2000 |
2600 |
|
Inner diameter(mm) |
800 |
1200 |
1500 |
1700 |
2000 |
2600 |
|
Canister length(mm) |
22000 |
3000 |
3000 |
4000 |
5000 |
10000 |
|
Number of lid sawtooth |
12 |
12 |
14 |
14 |
16 |
24 |
|
thickness of lid (mm) |
10 |
10 |
10 |
10 |
16 |
14 |
|
Thickness of the tank body(mm) |
10 |
10 |
10 |
10 |
12 |
14 |
|
Working pressure(Mpa) |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
0.55 |
|
Dimensions(mm) (length*width*height) |
22766*1445
|
4010*1575
|
3960*2150
|
4925*2162
|
6200*2590
|
11722*3360
|
|
Weight(Kg) |
5580 |
2017 |
2950 |
3835 |
6500 |
16775 |
Markets:
Mainly sold to Europe, America, South America, Southeast Asia, India and other countries.
Factory and certificates:
We can produce different size according to your pharameter requirement. and we allow proper discount according to the quantity you order.
We confident that you will find our product with high quality and reasonable price. If you have any question, contact me.
