SINOBAKE Twist Cookies Dough Drop Machine

SINOBAKE Twist Cookies Dough Drop Machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $220000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Voltage:: 380v

Power:: 15KW

Weight:: 10000 KG

Dimension(L*W*H):: MM

Materials::: 304 Stainless steel

Automatic::: PLC Controlled

Cylinder::: YSC Brand

Bearing::: NSK Brand from Japan

Gearbox::: S E W Brand from Germany

Transducer::: SIEMENS Brand

Motor::: SIEMENS Brand

Quality certificate::: ISO, CE certificate

Steel Band::: SANDVIC Brand

Burner:: Weishaupt

Certification:: IOS, CE certificate

Quick Details

Marketing Type:: New Product 2021

Place of Origin:: Guangdong, China

Brand Name:: SINOBAKE

Voltage:: 380v

Power:: 15KW

Weight:: 10000 KG

Dimension(L*W*H):: MM

Materials::: 304 Stainless steel

Automatic::: PLC Controlled

Cylinder::: YSC Brand

Bearing::: NSK Brand from Japan

Gearbox::: S E W Brand from Germany

Transducer::: SIEMENS Brand

Motor::: SIEMENS Brand

Quality certificate::: ISO, CE certificate

Steel Band::: SANDVIC Brand

Burner:: Weishaupt

Certification:: IOS, CE certificate

The price in the this table is only for reference. The exact price needs to be decided by the real solution.

Product Description

SINOBAKE Twist Cookies Dough Drop Machine

In addition to soft biscuit,soda biscuit,crackers, there is an important type of biscuit product is cookies. The cookies can be classified as wire cut cookies,depositor cookies,two-color cookies,tricolor cookies etc., with different equipment can increase the diversity of products and improve product taste.

FEATURES FOR COOKIE MACHINE

1.Fully servo motors controlled 2.Easy to operate with touch screen 3.Easy to clean and discharge for all dough flow channel mold components 4.Gear pump control the each cookie weight accurately 5.One machine can make single color,dual colors and three colors cookies.

A WHOLE COOKIE LINE USUALLY INCLUDES FOLLOWING MACHINE

1.Vertical dough mixer(300L)

2.Tilting Machine
3.Auto dough feeding system
4.Cookie machine--one color cookie machine,two colors cookie machine,three colors cookie machine
5.Electric oven(gas,diesel ovens are available. The length depends on the capacity you need)
6.Out oven machine
7.Cooling conveyor
8.Penny stacker
9.Packing table
Enter oven machine,sugar&salt sprinkler, are suggested to added, if your space is available.
The following description of each machine are based on standard one:

Dough mixer

It is for mixing soft biscuit and cookie dough, which contains more oil &fat.

300L/time, Three vertical blades

Tilting machine

Tilting machine is used to pour the dough from trolley into the hopper of the dough feeding system. We have 500kgs/time and 1000kgs/time for your choice.

We can also provide Hydraulic tilting machine.

Auto dough feeding system

Auto Dough feeding system is used for breaking the dough into small pieces and sending them to the cookie machine.

Cookie Machine

One color,two colors and three colors cookie machine can be provided. And we have wire cut cookie machine,blade cutting cookie machine,depositor machine, extruded cookie machine, en-crusted cookie machine.

Enter oven machine

Enter Oven Machine is used to send the formed biscuits into the oven, recycling the sugar, salt or reject biscuits.

Oven drive and tension system

mainly provide motive power to oven belt,drive the mesh belt,the mesh belt can be tensioned manually, pneumatic offset adjustment,the belt has brush cleaning device.

For the steel band oven, the oil device is suggested.

Tunnel oven

It is the baking equipment of the biscuit line,baking biscuit by indirect thermal radiation, making biscuit with fine color and flavour. For soft biscuits and cookies, convection oven is suggested. The oven heating source can be gas, electricity, diesel.

Out oven machine

it is used for conveying baked biscuit out of oven smoothly.
