Aluminum and other metal wall panels are a popular choice for interior and exterior commercial use.
These panels are often found on large office buildings or big retail centers. An aluminum wall panel provides a sleek and stylish
look, but also provides insulation. A true sandwich structure, an aluminum wall panel most often has a polyurethane foam
core,bonded between the aluminum skins and aluminum foil paper. Attractive, reasonably priced, easy to install and providing
insulation,metal wall panels are increasingly being used in new construction.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
DIBAIER
-
Package:
-
Thick carton, logo customized
-
Core material:
-
Polyurethane foam
-
Surface material:
-
Coated steel
-
Bottom material:
-
Aluminum foil paper ,waterproof
-
Length:
-
2-6 m
-
Thickness:
-
16mm 20 mm
-
fire rating:
-
B1 B2
-
Usage:
-
prefab houses, sentry
-
oxygen index:
-
>26%
-
Advantage:
-
shockproof ,saving time
Quick Details
-
Project Solution Capability:
-
3D model design, Others
-
Application:
-
Hotel
-
Design Style:
-
Modern
-
Place of Origin:
-
China
-
Brand Name:
-
DIBAIER
-
Package:
-
Thick carton, logo customized
-
Core material:
-
Polyurethane foam
-
Surface material:
-
Coated steel
-
Bottom material:
-
Aluminum foil paper ,waterproof
-
Length:
-
2-6 m
-
Thickness:
-
16mm 20 mm
-
fire rating:
-
B1 B2
-
Usage:
-
prefab houses, sentry
-
oxygen index:
-
>26%
-
Advantage:
-
shockproof ,saving time
Specification
Advantages and Function
|
Thickness
|
16mm/20mm
|
Fire resistance level
|
B1/B2
|
|
Width
|
383mm
|
Size toleranc
|
-/+2mm
|
|
Length
|
2000mm~6000mm
|
Tensile bond strength
|
0.17MPA
|
|
Surface steel
|
Galvalume,C type
|
Wind load value
|
9 KPA
|
|
Steel alloy composition
|
Aluminum 55%,Zinc 43.5%,Silicon 1.5%,ect.
|
Package
|
10 pieces/carton,8pieces/carton
|
|
Steel coating
|
HDP,>30um
|
Package Size
|
4010mm*41mm*170mm(10 pieces/carton)
4010mm*41mm*138mm(8 pieces/carton) |
|
Core material
|
Polyurethane,40kg/m3
|
OEM
|
Logo and panel size
|
|
Closed cell rate
|
90%~95%
|
Container load
|
20GP:1600sqm(panel length 1.82m)
40HC/HQ : 3800 sqm (panel length:3.8m). 40NOR:3300 sqm(panel length:3.8m). |
|
Thickness of bottom material
|
0.026mm
|
After-sale Service
|
Online traing,online technical support
|
|
Panel weight
|
3.5~3.7kg/m2
|
Port
|
QINGDAO
|
|
R-VALUE
|
0.55 m2*k/w
|
Payment
|
T/T,L/C
|
|
Heat conductivity
|
0.024 w/m*k(in theory)
|
Brand
|
DIBAIER
|
|
Density
|
40- 60 （kg/m3)
|
Dimensional stability
|
≤ 1.5%
|
|
Compressive strength
|
200 - 270 （kpa）
|
Room temperature
|
-196℃ +120℃
|
|
Water absorption
|
≤3 %
|
Oxygen index
|
≥26 %
|
Product Description
(1) The surface material is Al-Zn Alloy Coated steel sheet
(2) The core material of the middle layer is a special fireproof hard high-density polyurethane foam insulation layer,
(3) The bottom material is aluminum foil .
(2) The core material of the middle layer is a special fireproof hard high-density polyurethane foam insulation layer,
(3) The bottom material is aluminum foil .
|
Property
|
Cement
|
Lumber
|
Gypsum board
|
Common wall
|
Pu sandwich panels
|
|
Thermal conductivity
|
0.13
|
1.1
|
0.5
|
0.15
|
0.018
|
|
Thickness comparison
|
72.30mm
|
612mm
|
278mm
|
83.4mm
|
16mm
|
INSTALLATION
The panel is fixed by screws and trim . We provide accessories for installation the panel .
Design
Company Introduction
Jinan Dibaier Environmental Protection Material Co.,Ltd
J
inan Dibaier Environmental Protection Materials Co., Ltd. is a high-tech enterprise combining with design,development,
manufacturing, sales and service of metal carving board, activity room and booth.New wall materials of Dibaier have features like good thermal insulation, sound insulation and noise reduction effects,light weight, high strength, simple construction and corrosion resistance. The appearance is elegant and reusable.And its service life is long and the weather resistance is good. The company has strong technical strength,standardized management and perfect technology. With professional technology, leading
equipment, scientific management and excellent service,we have won wide acclaim from all walks of life. Our products can be used in the following fields: high-rise buildings, modern villas, light steel workshops,mobile homes, European and American boxes,
renovation of exterior walls of old buildings, movement of scenic spots and permanent houses, environmentally friendly public
toilets, various beautiful and energy-saving buildings.
manufacturing, sales and service of metal carving board, activity room and booth.New wall materials of Dibaier have features like good thermal insulation, sound insulation and noise reduction effects,light weight, high strength, simple construction and corrosion resistance. The appearance is elegant and reusable.And its service life is long and the weather resistance is good. The company has strong technical strength,standardized management and perfect technology. With professional technology, leading
equipment, scientific management and excellent service,we have won wide acclaim from all walks of life. Our products can be used in the following fields: high-rise buildings, modern villas, light steel workshops,mobile homes, European and American boxes,
renovation of exterior walls of old buildings, movement of scenic spots and permanent houses, environmentally friendly public
toilets, various beautiful and energy-saving buildings.
Packing&Shipping
Packing:Carton packaging + Packaging belt
About 3.5-3.7kg per square meter.
(1) Board cabinet size:
It is generally required to be 5.8m for 20 foot cabinet,
According to the needs of customers, the total length of 40 foot cabinet is less than 11.8 meters
(2) Loading information:
The size and specification of the 20 foot small cabinet is about 5.898 × 2.352 × 2.385m, and the assembly level is about 1300 (excluding spare parts space)
40 large cabinet (high cabinet): 12.032 × 2.352 × 2.69M, about 3300 flat (excluding spare parts space)
About 3.5-3.7kg per square meter.
(1) Board cabinet size:
It is generally required to be 5.8m for 20 foot cabinet,
According to the needs of customers, the total length of 40 foot cabinet is less than 11.8 meters
(2) Loading information:
The size and specification of the 20 foot small cabinet is about 5.898 × 2.352 × 2.385m, and the assembly level is about 1300 (excluding spare parts space)
40 large cabinet (high cabinet): 12.032 × 2.352 × 2.69M, about 3300 flat (excluding spare parts space)
FAQ
Q:Are you trading company or manufacturer?
A:We are factory .Welcome to visit our company.The main products are PU and EPS sandwich panels .
Q:How long is your delivery time?
A:Generally it is 5-10 days if the goods are in stock.Or it is 10-15 days if the goods are not in stock.It is according to
quantity.
Q:Do you provide samples?Is it free or extra?
A:Yes.We could offer the sample for free (5 pcs).But do not pay the cost of freight.
Q:How to guarantee clients interests?
A:You can pay via Alibaba.It can guarantee the quality and delivery time.
Q:Do you offer OEM service?
A:We accept OEM orders , including clients logos and labels.(Min order: 500 square meters )
Q How many payment methods are there?
We accept the T/T ,L/C, Paypal ,Secured transactions,etc
A:We are factory .Welcome to visit our company.The main products are PU and EPS sandwich panels .
Q:How long is your delivery time?
A:Generally it is 5-10 days if the goods are in stock.Or it is 10-15 days if the goods are not in stock.It is according to
quantity.
Q:Do you provide samples?Is it free or extra?
A:Yes.We could offer the sample for free (5 pcs).But do not pay the cost of freight.
Q:How to guarantee clients interests?
A:You can pay via Alibaba.It can guarantee the quality and delivery time.
Q:Do you offer OEM service?
A:We accept OEM orders , including clients logos and labels.(Min order: 500 square meters )
Q How many payment methods are there?
We accept the T/T ,L/C, Paypal ,Secured transactions,etc
