Quick Details
-
Brand Name:
-
RUNTOP
-
Use:
-
FTTX
-
Warranty Time:
-
1 years
-
Product Name:
-
Passive Optical Receiver
-
Wavelength:
-
1200/1600nm
-
Responsivity:
-
≥0.85/≥0.9 A/W
-
Optical Return Loss:
-
≥45dB
-
Frequency Range:
-
45-1000MHz
-
Broadband/Uneven:
-
47~1000/≤±1.5 MHz/dB
-
Receiving Power Range:
-
wer Range: 0~-12(advice -1~-6) dBm
-
Optical Adapter:
-
SC/APC or SC/UPC(advice SC/APC)
-
Output Level:
-
65(0dBm receive)-47(-9dBm receive) dBuv
-
CNR/MER:
-
≥44/34(0dBm, PAL59CH,OMI3.8%), ≥38/29(-6dBm)
-
Certification:
-
CCC, ce
Quick Details
-
Type:
-
Optical Receiver
-
Model Number:
-
RTP0L
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
RUNTOP
-
Use:
-
FTTX
-
Warranty Time:
-
1 years
-
Product Name:
-
Passive Optical Receiver
-
Wavelength:
-
1200/1600nm
-
Responsivity:
-
≥0.85/≥0.9 A/W
-
Optical Return Loss:
-
≥45dB
-
Frequency Range:
-
45-1000MHz
-
Broadband/Uneven:
-
47~1000/≤±1.5 MHz/dB
-
Receiving Power Range:
-
wer Range: 0~-12(advice -1~-6) dBm
-
Optical Adapter:
-
SC/APC or SC/UPC(advice SC/APC)
-
Output Level:
-
65(0dBm receive)-47(-9dBm receive) dBuv
-
CNR/MER:
-
≥44/34(0dBm, PAL59CH,OMI3.8%), ≥38/29(-6dBm)
-
Certification:
-
CCC, ce
FTTH hfc catv Optical Receiver Mini Node Without filter which can be used for digital TV fiber to the home, it has high performance, lower receiver optical power and lower cost for CATV operators providing high quality and excellent FTTH network solution.
