Quick Details
-
Description:
-
SMD Package, Radar motion detection sensor module
-
Model Number:
-
AIM24-SB
-
Place of Origin:
-
South Korea
-
Brand Name:
-
AIM24
-
Theory:
-
Motion and position sensors
-
Output:
-
3.6~5V
-
Material:
-
PCB
-
Name:
-
AIM24-SB
-
Certification:
-
KC, TELEC, CE/CE ROHS, FCC
-
Composition:
-
Sensor
-
Size:
-
15 * 15 * 4.3mm
-
Payment:
-
100% Payment before Shipment
-
Color:
-
Dark blue
-
Detection Range:
-
Max 10 meter
-
Detection Angle:
-
109/45, Can detect movement direction
-
Operating Voltage:
-
3.6~5V
Quick Details
-
Use:
-
Motion Detection
-
Features:
-
Energy-saving/Internal algorithm,MCU/I2C interface
-
Mounting Type:
-
Others
-
Description:
-
SMD Package, Radar motion detection sensor module
-
Model Number:
-
AIM24-SB
-
Place of Origin:
-
South Korea
-
Brand Name:
-
AIM24
-
Theory:
-
Motion and position sensors
-
Output:
-
3.6~5V
-
Material:
-
PCB
-
Name:
-
AIM24-SB
-
Certification:
-
KC, TELEC, CE/CE ROHS, FCC
-
Composition:
-
Sensor
-
Size:
-
15 * 15 * 4.3mm
-
Payment:
-
100% Payment before Shipment
-
Color:
-
Dark blue
-
Detection Range:
-
Max 10 meter
-
Detection Angle:
-
109/45, Can detect movement direction
-
Operating Voltage:
-
3.6~5V
Product Description
Packing & Delivery
PACKAGE : Carrier reel + Box
CARTON SIZE : 1230*450*410 MM
Weight (Net/Gross): 30kg/50kg
Qty/Ctn: 25000ea/ctn
100,000ea per Month (supply)
Specification
|
item
|
value
|
|
Features
|
Energy-saving/Internal algorithm,MCU/I2C interface
|
|
Mounting Type
|
Others
|
|
Description
|
SMD Package
|
|
Model Number
|
AIM24-SB
|
|
Type
|
Motion & Position Sensor
|
|
Place of Origin
|
South Korea
|
|
Brand Name
|
AIM24
|
|
Usage
|
Motion Detection
|
|
Material
|
PCB
|
|
Name
|
AIM24-SB
|
|
Certification
|
KC, TELEC, CE/CE ROHS, FCC
|
|
Composition
|
Sensor
|
|
Size
|
15 * 15 * 4.3mm
|
|
Payment
|
100% Payment before Shipment
|
|
Color
|
Dark blue
|
|
Detection Range
|
Max 10 meter
|
|
Detection Angle
|
109/45, Can detect movement direction
|
|
Operating Voltage
|
3.6~5V
|
|
Current Consumption
|
10~48mA
|
|
Module Type
|
VSQP(Vertically Stacked Quad Package)
|
|
Communication Method
|
I2C
|
|
Operating Temperature
|
-40~85
|
