Quick Details
-
Operating System:
-
Android 11/13 (continuous updates)
-
Type:
-
Tablet PC
-
Weight:
-
1015g
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
T80
-
Sim card:
-
1.8/3.3V SIM card
-
Battery:
-
18900mAh
-
Anti-shake:
-
1-19Hz/1.0mm; 19-200Hz/1.0g
-
Anti-drip/IK:
-
MIL-STD-810G/Method 516.6/Procedure IV and Touch Panel IK05
-
reliability:
-
MTBF>5000h;MTTR<0.5h
-
water proof:
-
Category 7 (IEC 60529)
-
dust-proof:
-
Category 6 (IEC 60529)
Quick Details
-
Screen Size:
-
8"
-
Memory Capacity:
-
8GB
-
Display resolution:
-
1920*1200
-
Operating System:
-
Android 11/13 (continuous updates)
-
Type:
-
Tablet PC
-
Weight:
-
1015g
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
T80
-
Sim card:
-
1.8/3.3V SIM card
-
Battery:
-
18900mAh
-
Anti-shake:
-
1-19Hz/1.0mm; 19-200Hz/1.0g
-
Anti-drip/IK:
-
MIL-STD-810G/Method 516.6/Procedure IV and Touch Panel IK05
-
reliability:
-
MTBF>5000h;MTTR<0.5h
-
water proof:
-
Category 7 (IEC 60529)
-
dust-proof:
-
Category 6 (IEC 60529)
Product Description
Specification
|
Hardware
|
|
|
|
|
||||
|
CPU
|
|
ARM Cortex A73 octa-core (2.0GHz)
|
|
|
||||
|
GPU
|
|
Arm Mari-G72 MP3
|
|
|
||||
|
RAM
|
|
8 grams
|
|
|
||||
|
internal memory
|
|
128G
|
|
|
||||
|
main camera
|
|
13.0mp (AF) with flash LED
|
|
|
||||
|
Secondary camera
|
|
5.0MP
|
|
|
||||
|
Battery
|
|
18900mAh
|
|
|
||||
|
show
|
|
8-inch IPS/AFFS FHD 1920*1200 industrial 1000 nits sunlight readable
|
|
|
||||
|
touch panel
|
|
Capacitive/frosted tempered film supports glove touch/spraying/active capacitive pen
|
|
|
||||
|
IO/sensor/navigation
|
|
|
|
|
||||
|
Sim card
|
|
Nano sim card*2
|
|
|
||||
|
TF card
|
|
Micro sd card (t-flash card); maximum 256gb
|
|
|
||||
|
charging port
|
|
Type-C & 4pin pogo pin (magnetic)
|
|
|
||||
|
Data interface
|
|
USB Type-A (Host) * 1, Type-C * 1
|
|
|
||||
|
UART (optical)
|
|
UART TTL3.3 X2 onboard
|
|
|
||||
|
RS232 (optional)
|
|
RS232X1
|
|
|
||||
|
RS485 (optical)
|
|
RS485X1
|
|
|
||||
|
Orientation sensor
|
|
support
|
|
|
||||
|
Gravity sensor
|
|
Support
|
|
|
||||
|
magnetic field sensor
|
|
Support
|
|
|
||||
|
motion sensor
|
|
Support
|
|
|
||||
|
Rotate vector
|
|
Support
|
|
|
||||
|
light sensor
|
|
Support
|
|
|
||||
|
Gyro sensor
|
|
Support
|
|
|
||||
|
Accelerometer
|
|
Support
|
|
|
||||
|
charger
|
|
5.0V 2A-10W
|
|
|
||||
|
temperature pressure sensor
|
|
Optional
|
|
|
||||
|
navigation
|
|
GPS + Beidou + Glonass + AGPS + SBAS (EPO 2.5m)
|
|
|
||||
|
Appearance
|
|
|
|
|
|
||||
|
size
|
|
256*159 * 23mm (length × width × height)
|
|
|
|
||||
|
weight
|
|
1015g
|
|
|
|
||||
|
color and material
|
|
Blue (Computer + ABS) + Black (TPU)
|
|
|
|
||||
|
Communications and Networking
|
|
|
|
|
||||
|
Telephone
|
|
GSM /WCDMA/CDMA 1X/VoLTE
|
|
|
||||
|
2G
|
|
GSM/Code Division Multiple Access 1X/Edge/GPRS/WAP
|
|
|
||||
|
2g band
|
|
GSM(B2/3/5/8)
|
|
|
||||
|
3G
|
|
WCDMA 3.75G (HSDPA + 44.2 Mbps, HSUPA + 11.5Mbps), EVDO
|
|
|
||||
|
3g band
|
|
WCDMA(B1/2/5/8), Evdo: BC0/BC1 CDMA: BC0/BC1
|
|
|
||||
|
4G
|
|
FDD: 150Mbps downlink, 50Mbps uplink TDD: 150Mbps downlink, 50Mbps uplink
|
|
|
||||
|
4g band
|
|
Td-lte (B38/39/40/41);FDD LTE(B1/2/3/4/5/7/8/12/17/20/28)
|
|
|
||||
|
Wi-Fi
|
|
Dual band (2.4GHz/5Ghz) single stream 802.11 a/b/g/n/ac
|
|
|
||||
|
British Telecom
|
|
5.0 Low Energy (LE)
|
|
|
||||
|
Industrial and Reliability Design
|
|
|
|
|
||||
|
Anti-shake
|
|
1-19Hz/1.0mm; 19-200Hz/1.0g
|
|
|
||||
|
Anti-drop/IK
|
|
MIL-STD-810G/Method 516.6/Procedure IV and Touch Panel IK05
|
|
|
||||
|
water proof
|
|
Category 7 (IEC 60529)
|
|
|
||||
|
dust-proof
|
|
Category 6 (IEC 60529)
|
|
|
||||
|
reliability
|
|
MTBF>5000h;MTTR<0.5h
|
|
|
||||
|
operate
|
|
-20 ℃ to 55 ℃
|
|
|
||||
|
Storage temperature
|
|
-40 ℃ to 70 ℃
|
|
|
||||
|
RH
|
|
5% to 95%
|
|
|
||||
|
operating height
|
|
Maximum: 4,500 m (15,000 ft)
|
|
|
||||
|
Certification/OS/Software
|
|
|
|
|
|
||||
|
Certification
|
|
3C /FCC/CE/ROHS/IP67(IEC 60529)
|
|
|
|
||||
|
language
|
|
English, Spanish, Portuguese (Brazil), Portuguese (Portugal), Italian, German, Dutch, French, Polish, Romanian, Turkish, Russian,
Arabic, Indonesian , Malay, Thai, Vietnamese, Hindi, Hebrew, Simplified, Chinese, Traditional, etc. |
|
|
|
||||
|
operating system
|
|
Android 9/10/11/13 (continuous updates)
|
|
|
|
||||
|
Packaging/Warranty Terms/Original Equipment Manufacturer
|
|
|
|
|
||||
|
Warranty
|
|
24 months (non-human damage)
|
|
|
||||
|
OEM/ODM
|
|
Support
|
|
|
||||
|
Package
|
|
USB cable/Charger 5V 2A/Introduction manual/Screen protector/Packaging box (customizable logo)/Tool kit (optional) sim card
injector x 1/Magnetic charging cable |
|
|
||||
Certifications
Packing & Delivery
|
Packaging Details
|
Product size: 256*159 * 23mm
Box size: 370*260 * 170mm Quantity per carton: 860g N.W: 1015g G.W: 2030g Carton size: 340*260 * 310mm 10 sets/carton |
