Quick Details
-
Weight:
-
1.0kg
-
Size:
-
10 inch, 20 inch, 30 inch, etc
-
Power:
-
1
-
Weight (KG):
-
1 kg
-
Filter Type:
-
50 Microns Pleated Filter Cartridge
-
Membrane:
-
Polypropylene
-
Micron:
-
0.1, 0.2, 0.3, 0.45, 0.65, 1.0, 3.0, 5.0, 10 um
-
Cage, Core:
-
Polypropylene
-
Length:
-
5, 10, 20, 30, 40 inch
-
Adapter:
-
DOE, Code 7, 226, 222, etc
-
Filtration Efficiency:
-
99%
-
Application1:
-
Wine, Beer, Mineral Water Plant
-
Application2:
-
Chemical Solutions
-
Application3:
-
Air, Gas Filtration
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TS Filter
-
Material:
-
Carton
-
Weight:
-
1.0kg
-
Size:
-
10 inch, 20 inch, 30 inch, etc
-
Power:
-
1
-
Weight (KG):
-
1 kg
-
Filter Type:
-
50 Microns Pleated Filter Cartridge
-
Membrane:
-
Polypropylene
-
Micron:
-
0.1, 0.2, 0.3, 0.45, 0.65, 1.0, 3.0, 5.0, 10 um
-
Cage, Core:
-
Polypropylene
-
Length:
-
5, 10, 20, 30, 40 inch
-
Adapter:
-
DOE, Code 7, 226, 222, etc
-
Filtration Efficiency:
-
99%
-
Application1:
-
Wine, Beer, Mineral Water Plant
-
Application2:
-
Chemical Solutions
-
Application3:
-
Air, Gas Filtration
PRODUCT CATEGORIES
PARAMETER INFORMATION
|
Materials Of Construction
|
Filter Media:
|
Polypropylene Membrane
|
|
|
|
Micron Rating:
|
0.1, 0.2, 0.45, 0.65, 1.0, 3.0, 5.0, 10, 20, 30, 50, 100um
|
|
|
|
Support Layers:
|
Polypropylene
|
|
|
|
Cage, Core, End Cap:
|
Polypropylene
|
|
|
|
Seal Method:
|
Thermal Bonded, No Adhesives
|
|
|
|
O-rings/Gaskets:
|
Silicone, Nitrile, EPDM, Viton, etc
|
|
|
Cartridge Dimensions
|
Outer Diameter:
|
69mm
|
|
|
|
Inner Diameter:
|
33mm
|
|
|
|
Length:
|
5, 10, 20, 30, 40 Inch
|
|
|
|
Filtration Area(m2):
|
0.65 m2 per 10"
|
|
|
Operating Conditions
|
Normal Operating Temp.:
|
Up to 60℃
|
|
|
|
Max. Operating Temp.:
|
80℃
|
|
|
|
Max. Differential Pressure
|
|
|
|
|
Normal Flow:
|
4.2 bar at 25℃
|
|
|
|
Reverse flow:
|
2.1 bar at 25℃
|
|
|
|
PH Value compatibility:
|
1-13
|
|
|
|
Sterilization:
|
Steam Sterilization for 30 minutes at 121±2 ℃, Cumulative Time:15 hours
|
|
|
|
|
Flush with hot water at 82℃(180℉) for 30 minutes, at P≤1.0 bar (14psi)--Recommended.
|
|
|
Cartridge Safety
|
Endotoxin:
|
＜0.25 EU/ml
|
|
|
|
Extractables:
|
＜0.03 g/10"
|
|
Typical water flow rate @ 25℃(10")
APPLICATION
COMPANY PROFILE
EXHBITION
WHY CHOOSE US
PACKING AND SHIPPING
FAQ
1. How can we get the quotation of filters?
Kindly please let us know the specifications, such as membrane material, micron, length, adapter, etc,
2. What's the minimal order quantity?
We don't have MOQ on filters, sample order is available,
3 . How long about your delivery?
Sample order is about 4 days, formal order depends on your quantity, please contact us,
Kindly please let us know the specifications, such as membrane material, micron, length, adapter, etc,
2. What's the minimal order quantity?
We don't have MOQ on filters, sample order is available,
3 . How long about your delivery?
Sample order is about 4 days, formal order depends on your quantity, please contact us,
