Quick Details
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
guose
-
Model Number:
-
JZXF200806
-
Product name:
-
Prefabricated container house
-
keyword:
-
detachable container/container house/ prefab house
-
Color:
-
As shown or customized
-
Usage:
-
Villa/mall/warehouse/workshop
-
Feature:
-
waterproof/fireproof/anticorrosive
-
Floor:
-
Cement-fibre Board
-
Certification:
-
ISO9001
-
Size:
-
20ft(5800*2800*2800)/40ft(11600*2800*2800)
-
Advantage:
-
removable/reusable
-
Main material:
-
Sandwich Pannel+steel structure
Quick Details
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, NONE, Others
-
Application:
-
Hotel
-
Product Type:
-
Container Houses
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
guose
-
Model Number:
-
JZXF200806
-
Product name:
-
Prefabricated container house
-
keyword:
-
detachable container/container house/ prefab house
-
Color:
-
As shown or customized
-
Usage:
-
Villa/mall/warehouse/workshop
-
Feature:
-
waterproof/fireproof/anticorrosive
-
Floor:
-
Cement-fibre Board
-
Certification:
-
ISO9001
-
Size:
-
20ft(5800*2800*2800)/40ft(11600*2800*2800)
-
Advantage:
-
removable/reusable
-
Main material:
-
Sandwich Pannel+steel structure
Product Description
|
Parts
|
Part Name
|
Standard material
|
Optional
|
|
Top frame system
|
Upper corner piece
|
3.5mm upper corner piece, zinc plating amount 80g/㎡ 210*150*210mm
|
no
|
|
|
Main beam of roof (long)
|
3.0mm galvanized forming beam, zinc plating amount 80g/㎡, width: 170mm, length: 5633mm
|
2.0mm-3.0mm
|
|
|
Roof main beam (short)
|
3.0mm galvanized forming beam, galvanizing amount 80g/㎡, width: 170mm, length: 2688mm
|
2.0mm-3.0mm
|
|
|
Roof roof
|
75mm glass wool + tin foil paper, 14kg/m³
|
0.4mm-0.6mm
|
|
|
Roof insulation
|
C-shaped steel 90*1.3mm, square tube 20*20*1.0mm, galvanizing amount 80g/㎡
|
100mm
|
|
|
Roof secondary beam
|
0.4mm, 831 color steel integrated ceiling board, laminated
|
Negotiable
|
|
|
Ceiling board
|
Electrostatic spraying (white)
|
0.4mm-0.6mm
|
|
|
Surface treatment
|
3.5mm upper corner piece, galvanizing amount 80g/㎡ 210*150*160mm
|
Color can be customized
|
|
Low frame system
|
Lower corner pieces
|
3.0mm galvanized forming beam, zinc plating amount 80g/㎡, width: 160mm, length: 5633mm
|
no
|
|
|
Ground main beam (long)
|
3.0mm galvanized forming beam, galvanizing amount 80g/㎡, width: 160mm, length: 2688mm
|
2.0mm-3.0mm
|
|
|
Ground main beam (short)
|
1.6mm floor leather
|
2.0mm-3.0mm
|
|
|
Floor paving
|
1.0mm waterproof membrane
|
1.0mm floor leather, 1.6 plastic floor, 2.0 plastic floor, wooden floor
|
|
|
Waterproof membrane
|
18mm cement modified board
|
no
|
|
|
ground
|
75mm glass wool + tin foil paper, 14kg/m³
|
15mm cement modified board, 18mm cement fiber board, 15mm multilayer board
|
|
|
Ground insulation
|
75mm glass wool + tin foil paper, 14kg/m³
|
100mm
|
|
|
Roof secondary beam
|
3.0mm galvanized column, zinc plating amount 80g/㎡ 210mm*150mm, height 2520mm
|
Negotiable
|
|
|
Back cover color steel plate
|
Ø50mm, white PVC
|
0.4mm-0.6mm
|
|
|
Surface treatment
|
75mm color steel rock wool sandwich panel, 0.4mm/0.4mm, bulk density 50kg/m³
|
Color can be customized
|
|
Wall system
|
Prism
|
3.0mm galvanized column, zinc plating amount 80g/㎡ 210mm*150mm, height 2520mm
|
2.0mm-3.0mm
|
|
|
Drain pipe
|
Ø50mm, white PVC
|
no
|
|
|
Wall panel
|
75mm color steel rock wool sandwich panel, 0.4mm/0.4mm, bulk density 50kg/m³
|
50mm/100mm, 0.4mm-0.6mm, 50kg-120kg/m³
|
|
|
High-equipped anti-theft door
|
840mm*2035mm, made of steel
|
970mm*1970mm, equipped with anti-theft door
|
|
|
High-equipped anti-theft window
|
1130mm*1130mm, double glass double push
|
925mm*1130mm, single glass single push plastic steel window
|
