Whole cover with ABS Resin plastic , have excellent comprehensive physical, impact resistance ,Stability, two-thirds lighter weight than iron.
Automobile-grade,Robot-painting .
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Youyuan
-
Place of Origin:
-
Shandong, China
-
Size:
-
2160*1150*1680mm
-
Material:
-
ABS
-
Color:
-
Black, White, Red, Green, Sliver, Grey
-
Display:
-
LCD Display
Quick Details
-
Power:
-
> 1000W
-
Voltage:
-
60V
-
Tire Size:
-
Front 120/70-R12 Rear135/70-R12
-
Brand Name:
-
Youyuan
-
Place of Origin:
-
Shandong, China
-
Size:
-
2160*1150*1680mm
-
Material:
-
ABS
-
Color:
-
Black, White, Red, Green, Sliver, Grey
-
Display:
-
LCD Display
Specification
The integrate LED head &rear-light
Turn lights, brake lights, reverse lights. Low power consumption and increase 50% more in light transmittance.
CCC certified tempered and laminated glass Improve visual and more safety.
LCD display, volt meter, power meter, kilometer and reverse camera,plus Bluetooth, MP5,USB connector.
AC Motor (3000W)
AC motor with auto-hold function, powerful and water proof, lower noise, no carbon brush, maintenance-free. Equipped with automatic parking function
Battery
Lithium Iron Phosphate battery with BMS system,Large-capacity, safety and long using life.
2,000 times charging cycles(8-10 years) under working environment from -20 to 80 °C. Equipped with a fast charge ,to achieve full
charge within 2-3 hours.
2,000 times charging cycles(8-10 years) under working environment from -20 to 80 °C. Equipped with a fast charge ,to achieve full
charge within 2-3 hours.
Front-disc and Rear-drum dual circuit hydraulic brake.
|
Standard Configuration
|
|
|
||
|
|
Item
|
Electric Tricycles
|
||
|
Parameter
|
L*W*H (mm)
|
2160*1150*1680
|
||
|
|
Wheel Base (mm)
|
1555
|
||
|
|
Max. Speed (km/h)
|
45
|
||
|
|
Max. Range (km)
|
95
|
||
|
|
Capacity (Person)
|
2-3
|
||
|
|
Curb Weight (kg)
|
310
|
||
|
|
Min. Ground Clearance (mm)
|
160
|
||
|
|
Steering Mode
|
Middle Handlelar
|
||
|
Power System
|
A/C Motor
|
60V 3000W
|
||
|
|
Lithium Battery
|
105Ah LiFePo4 Battery
|
||
|
|
Charging Time
|
2-3 hrs (220V)
|
||
|
|
Charger
|
Intellengent Charger
|
||
|
Brake System
|
Type
|
Hydraulic System
|
||
|
|
Front
|
Disc
|
||
|
|
Rear
|
Disc
|
||
|
Suspension System
|
Front
|
Independent Double Wishbone
|
||
|
|
Rear
|
Integrated Rear Axle
|
||
|
Wheel Suspension
|
Tyre
|
Front: 120/70-R12
Rear: 135/70-R12
|
||
|
|
Wheel Hub
|
Aluminum Alloy Hub
|
||
|
Function Device
|
Multi-media
|
MP5+Reverse Camera
|
||
|
|
Electric Heater
|
60V 800W
|
||
|
|
Central Lock
|
Auto Level
|
||
|
|
One Button Start
|
Auto Level
|
||
|
|
Electric Door&Window
|
2
|
||
|
|
Skylight
|
Manual
|
||
|
|
Seats
|
Leather
|
||
|
Kindly Note: All configuartions is only for your reference in accorance with EEC homologation
|
|
|
||
Product Advantages
CKD(Completely knocked down)assembly reduce and save customsduty and transport cost.
Car-sharing personal&commercial APP,to manage and montior all vehicles.
Fast charger with 2~3 hours under home charger,power consumption cost of each 100 km is less than 0.5$.
Free Charger charging your EV like mobile , makes more freedom, No need dedicated charging stations
Packaging&Delivery
Certification
Production Process
FAQ
|
Q1. Are there any other options for this car?
|
|
A:Yes, different body colors, Seat belts, sunshade Cover, MP3 player, Spare tire, with door/without door, Custom logo, or any
other optional as your requirement. |
|
Q2. How about the delivery time?
|
|
Generally, it will take 15 to 25 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order
|
|
Q3. Do you provide operational manual?
|
|
Yes, we provide them. The operational manual will be sent together with the vehicles.
|
|
Q4. What's your payment term?
|
|
A:T/T 30% deposit and balance before shipment. We'll show you the photos of the products and packages before you pay the balance.
|
|
Q5. How long the batteries need to charge?
|
|
A: Normally, 6-8hours in full charge. 2 hours with fast charger.
|
|
Q6. What's the Max Climbing Capability?
|
|
A: Max climbing capability is 30%.
|
|
Q7. Do you provide Trade Assurance via Alibaba?
|
|
A:Yes, we do. Trade Assurance orders is welcomed!
|
|
Q8. How long will the batteries last ?
|
|
The range of the vehicle depends on a number of things
|
|
Q9. What is your warranty period:
|
|
3 years for battery; 1 year for whole cars.
|
