Quick Details
-
Top speed:
-
55km/h
-
Transmission:
-
CVT
-
Brake:
-
Front Dual Hydraulic Disk Rear Single Axle Hydraulic Disk
-
Color:
-
red blue yellow white green
-
Final Drive:
-
chain-drive
-
Drive Line Type:
-
4x2
-
Ignition System:
-
C.D.I
-
Suspension:
-
Front: double A-Arm, Rear: Dual Shock Swing arm
Quick Details
-
Brand Name:
-
FANGPOWER
-
Place of Origin:
-
Shandong, China
-
Horse Power:
-
7.6kw(7000r/min) 10.5HP
-
Top speed:
-
55km/h
-
Transmission:
-
CVT
-
Brake:
-
Front Dual Hydraulic Disk Rear Single Axle Hydraulic Disk
-
Color:
-
red blue yellow white green
-
Final Drive:
-
chain-drive
-
Drive Line Type:
-
4x2
-
Ignition System:
-
C.D.I
-
Suspension:
-
Front: double A-Arm, Rear: Dual Shock Swing arm
Product Description
Product specification
|
Model Style FX200 Tiger
|
SUSPENSION / BRAKES
|
||||
|
Final Drive
|
Chain-drive
|
Suspension Front
|
Double A-arm optional
|
||
|
Engine type
|
4-stroke,Single-Cylinder, Air/Oil-cooled
|
Suspension Rear
|
Dual Shock Swing arm
|
||
|
Horse Power
|
7.6kw(7000r/min) 10.5HP
|
Brakes Front
|
Front Dual Hydraulic Disk
|
||
|
Valve Configuration
|
OHV
|
Brakes Rear
|
Rear Single Axle Hydraulic Disk
|
||
|
Compression ratio
|
9.0:1
|
TIRES
|
|||
|
FUEL SYSTEM
|
Front Tread
|
1020mm ( 40.2 in)
|
|||
|
Fuel Delivery System
|
Fuel Pump Carburetor
|
Rear Tread
|
1040mm ( 41in)
|
||
|
Choke System
|
Automatic
|
Front & Rear tire size
|
21x7-10 / 22x10-10 ALUMINUM RIM
|
||
|
Fuel capacity
|
9.5L (2.1 Gallon)
|
MISC
|
|||
|
DRIVETRAIN
|
Loading information
|
8 units/20″; 26units/40HQ
|
|||
|
Driveline Type
|
4X2
|
Manufacturers Warranty
|
6 Months
|
||
|
Transmission
|
Constantly Variable Transmission
|
Top speed
|
55km/h
|
||
|
Gear Selection
|
Forward & Reverse Single Speed
|
Dry weight
|
290kgs ( 540 lbs.)
|
||
|
ELECTRICAL SYSTEM
|
Gross weight
|
360kgs(617lbs)
|
|||
|
Forward Lights
|
Headlights-High & Low Beam
|
Wheelbase
|
1885mm (74.2in)
|
||
|
Rear Lights
|
Brake Lights & Left/Right Signal lights
|
Vehicle dimension(L×W×H)
|
2450x1270x1670mm
|
||
|
Starting system
|
Electric start
|
Packing size
|
2290x1300x815mm (90.2x51.2x32.1in)
|
||
|
Ignition system
|
C.D.I
|
Ground clearance
|
180mm (7in)
|
||
|
Safety
|
Driver & Passenger Seat belts/ Driver and Passenger safety net restraints.
|
||||
