-Water supply from wells or reservoirs -livestock watering, dewatering -Industrial cooling and processing -Water distribution and pressure boosting, Etc
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
JARDEASY
-
Model Number:
-
3SD
-
Place of Origin:
-
Zhejiang, China
-
Horsepower:
-
0.33hp,0.5hp,0.75hp,1.0hp,1.5hp
-
Cable Length:
-
1.5m
-
Outlet Size:
-
1.25"
-
Power:
-
0.25kw,0.37kw,0.55kw,0.75kw,1.1kw
-
Motor:
-
100% Copper Wire Class F Built-in thermal protector
-
Pump body:
-
Stainless steel
-
Max. immersion depth:
-
100m
-
Minimum well diameter:
-
3"
-
MOQ:
-
30pcs
-
Insulation:
-
class B
-
Outlet/Inlet:
-
Cast-Cu
-
Bearing:
-
C&U
-
Shaft:
-
AISI304
-
Maximum sand content:
-
1500g/m3
Quick Details
-
Application:
-
Commercial Buildings, Family Homes, Irrigation and Agriculture, Other
-
Pressure:
-
High Pressure
-
Voltage:
-
220V-240V/50HZ
-
Warranty:
-
1 year
-
Brand Name:
-
JARDEASY
-
Model Number:
-
3SD
-
Place of Origin:
-
Zhejiang, China
-
Horsepower:
-
0.33hp,0.5hp,0.75hp,1.0hp,1.5hp
-
Cable Length:
-
1.5m
-
Outlet Size:
-
1.25"
-
Power:
-
0.25kw,0.37kw,0.55kw,0.75kw,1.1kw
-
Motor:
-
100% Copper Wire Class F Built-in thermal protector
-
Pump body:
-
Stainless steel
-
Max. immersion depth:
-
100m
-
Minimum well diameter:
-
3"
-
MOQ:
-
30pcs
-
Insulation:
-
class B
-
Outlet/Inlet:
-
Cast-Cu
-
Bearing:
-
C&U
-
Shaft:
-
AISI304
-
Maximum sand content:
-
1500g/m3
Products Description
-Water supply from wells or reservoirs -livestock watering, dewatering -Industrial cooling and processing -Water distribution and pressure boosting, Etc
|
Operating conditions
|
Motor and pump
|
-Maximum fluid temperature: +35℃
-
Maximum allowable amount of sand 300 g/m3
-Minimum well diameter:3"
-Rewindable motor
-
Maximum immersion depth:100m
-Single-phase : 220V-240V / 50HZ
-Equip with start control box or digital auto-control box
-Class of Insulation:B
-Degree of Protection : IP 68
