Quick Details
-
Brand Name:
-
Hanast
-
Model Number:
-
HN-501B-1
-
Type:
-
silicone sealant, one component
-
Product name:
-
Silicone Adhesive Sealant
-
Hardness:
-
20-40 Shore
-
Packing:
-
100ml aluminum tube, 310ml, 2600ml plastic tube
-
Color:
-
Transparent,translucent,black,white,red
-
Application:
-
Car electrical appliances,led lamps
-
Feature:
-
Low viscosity, good flowing type
-
Appearance:
-
Semi-fluid,sticky
-
temperature resistance range:
-
- 50~250 ℃
-
dynamic viscosity (mPa.S):
-
12000~12000
Quick Details
-
CAS No.:
-
67763-03-5
-
Other Names:
-
silicone adhesive sealant
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hanast
-
Model Number:
-
HN-501B-1
-
Type:
-
silicone sealant, one component
-
Product name:
-
Silicone Adhesive Sealant
-
Hardness:
-
20-40 Shore
-
Packing:
-
100ml aluminum tube, 310ml, 2600ml plastic tube
-
Color:
-
Transparent,translucent,black,white,red
-
Application:
-
Car electrical appliances,led lamps
-
Feature:
-
Low viscosity, good flowing type
-
Appearance:
-
Semi-fluid,sticky
-
temperature resistance range:
-
- 50~250 ℃
-
dynamic viscosity (mPa.S):
-
12000~12000
Waterproof Silicone Adhesive Sealant UV resistant Silicone Rubber Glue for Automobile Headlight LED Lamps
|
Model
|
HN-501C-1
|
HN-501C-2
|
HN-501B-1
|
HN-501R-1
|
HN-501W-1
|
HN-501W-2
|
|
Type
|
Ketoxime RTV
|
Alcohol
RTV |
Ketoxime RTV
|
Ketoxime RTV
|
Ketoxime RTV
|
Ketoxime RTV
|
|
Exterior
|
transparent flowing
|
Translucent semi-fluid
|
black, semi-fluid
|
red, flowing
|
white, flowing
|
White,flowing/
semi-flowing |
|
Viscosity (mPa.S)
|
12000~12000
|
12000~15000
|
3800~4000
|
12500~15000
|
16000~18000
|
20000-30000
|
|
Specific gravity (25℃)
|
1.0~1.04
|
0.98~1.0
|
1.0~1.1
|
1.0~1.1
|
1.0~1.1
|
1.0~1.1
|
|
Surface dry time (min25℃)
|
10~30
|
5~15
|
10~30
|
10~30
|
10~30
|
5~15
|
|
Shore hardness (JISA)
|
20~40
|
20~40
|
20~40
|
20~40
|
20~40
|
30~40
|
|
Elongation at break (%)
|
200~280
|
300~400
|
200~280
|
200~280
|
200~280
|
250~300
|
|
Tensile strength (Kgf/cm2)
|
15~30
|
15~30
|
15~30
|
15~30
|
15~30
|
10~30
|
|
Volume resistivity (Ω.cm)
|
≥3×1014
|
≥3×1014
|
≥3×1014
|
≥3×1014
|
≥3×1014
|
≥3×1014
|
|
Breakdown voltage (kv/mm)
|
18～25
|
18～25
|
18～25
|
18～25
|
18～25
|
18～25
|
|
Positive dielectric loss angle (1MHZ)
|
≤4×10-3
|
≤4×10-3
|
≤4×10-3
|
≤4×10-3
|
≤4×10-3
|
≤4×10-3
|
|
High and low temperature resistance (℃)
|
-50℃～250℃
|
-50℃～250℃
|
-50℃～250℃
|
-50℃～250℃
|
-50℃～250℃
|
-50℃～250℃
|
Product series: HN-501 series
Product use:
Widely used in bonding, fixing, sealing, electrical, insulation, antifouling, shockproof, coating, electronic appliances and
integrated small household appliances, LED lighting, instrument analysis, etc.
Product characteristics:
◆ Low viscosity, good flowing type
◆ High transparency and high physical and mechanical properties
◆ Excellent insulation performance
◆ It has moisture-proof, dust-proof, corona proof and anti-seismic buffer functions
◆ Good high and low temperature resistance, temperature resistance range: - 50~250 ℃
◆ Excellent aging resistance, service life up to 20~30 years
◆ After curing, the colloid will not turn yellow and leak oil, with excellent comprehensive performance
Product use:
Widely used in bonding, fixing, sealing, electrical, insulation, antifouling, shockproof, coating, electronic appliances and
integrated small household appliances, LED lighting, instrument analysis, etc.
Product characteristics:
◆ Low viscosity, good flowing type
◆ High transparency and high physical and mechanical properties
◆ Excellent insulation performance
◆ It has moisture-proof, dust-proof, corona proof and anti-seismic buffer functions
◆ Good high and low temperature resistance, temperature resistance range: - 50~250 ℃
◆ Excellent aging resistance, service life up to 20~30 years
◆ After curing, the colloid will not turn yellow and leak oil, with excellent comprehensive performance
Packing & Delivery
Aluminum tube + color box + K/A paper dividers + carton box
100 ml is packed in aluminum tube
Both 310 ml and 2600 ml are packaged in plastic tubes
100 ml is packed in aluminum tube
Both 310 ml and 2600 ml are packaged in plastic tubes
