Quick Details
-
CPU:
-
Hi3798M quad core--ARM Cortex-A7,CPU 1.5GHZ
-
Flash:
-
4GB/8G flash,NAND,EMMC
Quick Details
-
Processor Core:
-
Quad Core
-
Support Resolution:
-
1920 x 1080
-
WiFi:
-
802.11ac
-
CPU:
-
Hi3798M quad core--ARM Cortex-A7,CPU 1.5GHZ
-
Flash:
-
4GB/8G flash,NAND,EMMC
| Hardware Spec. | |||||||
| Operation System | Android 4.4.2 | ||||||
| Languages | Multi langages | ||||||
| CPU | Hi3798M quad core--ARM Cortex-A7,CPU 1.5GHZ | ||||||
| GOP | inner high performance 2D | ||||||
| Storage | LPDDR2,DDR3,DDR3L,1GB | ||||||
| Flash | 4GB/8G flash,NAND,EMMC | ||||||
| Power Supply | DC12V/1A | ||||||
| Outer Interface | |||||||
| HDMI output | 1xHDMI A , HDMI1.4A | ||||||
| USB interface | 2XUSB | ||||||
| AV output interface | RCA | ||||||
| Ethernet Interface | 1xRJ45 | ||||||
| Optic Interface | 1XSPDIF | ||||||
| Power Supply Interface | 1xDC (DC 3.5mm) | ||||||
| Antenna | internal Wi-Fi | ||||||
| Card Reader | 1xMicro SD(TF) | ||||||
| Network | |||||||
| Wi-Fi | Wi-Fi 802.11 b/g/n | ||||||
| Cable Network | 10M/100M BaseT | ||||||
| Audio&Video | |||||||
| Audio Format | Support MP3, WMA, CBR, VBROGG, APE, FLAC, WAV, AAC, AudibleRA, AC3, dts, MIDI, AMR, AIFF, MPC etc Support MP3,WMA,WAV,AC3,AAC,dts | ||||||
| Audio Output | HDMI,AV output | Dolby optional | |||||
| Video Decoding |
Support MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC-1,RV,VP6/VP8,Sorenson Spark,MVC Video format
1080P,60fps,3096*2016P,30fps,1080P,30fps. |
Support 4K | |||||
| Audio Encoding Format |
H.264 UP to HP,level4.1,MVC,VP8.
1920*1080(full HD) 1920*1080,25FPS |
||||||
| Video Decoding | HDMI 1.4,1080P,60HZ. | ||||||
| H.264,H.265 Frame Rate | 60Mbps,(Including 1080P H.265 Hardware Decoding) | ||||||
| Picture Format | Support JPEG,JPG,BMP,GIF,PNG,JFIF, Max Resolution 8192*8192 | ||||||
| External App | Google Store, App | ||||||
| DLNA,Miracast Protocol | Support | ||||||
| Remote | remote controller, mobile control, or 2.4Ghz wireless mouse | ||||||
| Other: | |||||||
| Working Temperature | -10~40℃ | ||||||
| Storage Temperature | -20~50℃ | ||||||
| Humidity | 5%-90%(non-condestation) | ||||||
| Cerificiate | CCC,CE,EMC,FCC,Wi-Fi certificate | ||||||
| Packing | |||||||
| Size | 20*19.8*1.7 | ||||||
| Net Weight | 0.55KG | ||||||
| Color Size | 21.5*17*6.5 | ||||||
| Packing | 580*324*245 | ||||||
Q1: How could I test IPTV system?
We will provide on-line test by our cloud server or help install local server for customer test.
Q2: Could I add some function or design UI interfaces ?
Yes, We have powerful R&D strength to tailor customer's requirements.
Q3: How to make an order?
You can contact our sales by email, whatsapp, skype for quotation.
Q4: How to make payment?
You can make payment by bank TT, western union, Alipay, Paypal etc...
Q5: How about technical support?
We will provide on-line support by teamviewer or on-site support for our customer.
