Quick Details
-
Weight:
-
2200 kg
-
Product name:
-
Napkin Folding Machine
-
Finished Products:
-
Serviette Tissue
-
Speed:
-
500-550pcs/min
-
Jumbo roll max diameter:
-
1200 mm
-
Jumbo roll inner core diameter:
-
3 inches(76.2 mm)
Quick Details
-
Production Capacity:
-
500-550pcs/min
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
soontrue
-
Weight:
-
2200 kg
-
Product name:
-
Napkin Folding Machine
-
Finished Products:
-
Serviette Tissue
-
Speed:
-
500-550pcs/min
-
Jumbo roll max diameter:
-
1200 mm
-
Jumbo roll inner core diameter:
-
3 inches(76.2 mm)
Specification
|
Suitable jumbo roll size
|
14-17g/㎡,double layer napkin paper
|
|
Carton packing speed
|
19-23g/㎡,single layer napkin paper
|
|
Carton L
|
Jumbo roll expansion ratio 10%-35%
|
|
Carton W
|
Jumbo roll width scope is 250-340mm
|
|
Expanded size
|
Expanded standard sizes is 300x300mm
|
|
Mechnical Speed
|
130—160m/min, Around 550pcs/min
|
|
Manufacture Speed
|
500-550pcs/min
|
|
Jumbo roll max diameter
|
1200 mm
|
|
Jumbo roll inner core diameter
|
3 inches(76.2 mm)
|
|
Machine structure type
|
Connected structure
|
|
Tansmission type
|
Gear, sycho-belt and flat belt transmission
|
|
Roll-back structure
|
Air upper press and belt roll-sending
|
|
Forming type
|
Mechnical type and tri-angle 1/4 folding
|
|
Control type
|
Inverter control speed-adjustment and jog for paper-sending and electric control counting
|
|
Embossing type
|
Steel to wool roller embossing
|
|
Machine power
|
Motor power 2.2KW,Air press, no less than 0.5MPA
|
|
Printing type
|
Flexible printing
|
Product Description
Siemens control system
HMI control
Correction function
Lamination unit
Closed ink cartridge, auto ink feeding
Automatic separating mechanism
