Quick Details
-
Model Number:
-
LSUL181h
-
Max. Current:
-
30A
Quick Details
-
Max. Voltage:
-
240V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LIRRD
-
Model Number:
-
LSUL181h
-
Max. Current:
-
30A
| Type | LSUL181h | |
| Working Voltage | 100,110,115,120,127VAC | 220,230,240VAC |
| Resistance Load Switch Capacity | 30A | 15A |
| Power Consumption | <1W | <2W |
| Voltage Range | 85~110% | |
| Power Source Frequency | 50/60HZ | |
| Compensation For Interrupion | 100 hours (Chromium Battery) | |
| Control Electrical Life | 100000 Times | |
| Mechanical Life | 10000000 Times | |
| Action Number | 48 Operations | |
| Timing Control Range | 24 hours | |
| Average Error | <±2s/24h,20℃ | |
| Minimum Setting Unit | 30 minutes/Unit | |
| Minimum Setting Interval | 30 minutes | |
| Temperature | -20℃~ +60℃ | |
| Relative Humidity | <90% | |
| Weight | 165g | |
| Dimensions | 110*54*67 mm | |
| Installation | Din Rail 35mm & Panel | |
| Shell Material | PC Material, Proof Flame | |
Established in 1995, Zhejiang Lierd Relays Enterprise Co., Ltd has been focusing on the relays for industrial control for 24 years.
Main products are electromagnetic relay, solid state relay, time relay, relay socket, ampere/voltage meter, time switch, counter and so on.
The application covers deomestic appliances, automatic control equipments, powering generating facilities and power grids, vehicle appliances, instruments, electronic equipments, communication equipments, machine equipments, office facilities, etc.
LIRRD(our brand name) has been cooperating with one of a leading company in industrial control in Northeast Asia for about twenty years. Quality is always our first resonsibility in business.
LIRRD has passed the management system certifications ISO9001:2015, ISO14001:2015. Quality certificates CCC, CQC are approved for domestic market. CE, UL are qualified for export market.
Question: How to choose the right model of the timers?
Answer: 1. Three basic types of timers: Digital, mechanical, astronomical timers.
It depends on your preference. Mechanical timers can be set more intuitively. While digital timers have smaller time intervals.
If the timer should be adjusted along with the season changes, an astronomical timer is the only option.
2. Dimensions.
Check up the space for installation. And compare the space with the dimensions of the timers. Make sure the timer can be fit in.
3. Load capacity: Max. voltage, max. current.
For digital types of timers, KG316 has larger load capacity than THC15A and CN101A. If there is enough space for installation, KG316 will be a better choice for large load capacity.
Times can be customized with higher load capacity. Contact us if you have a special requirement.
