2021 High quality Multifunction automatical retreading tyre used autoclave industrial

Product details:
1.According your product to choose suitable heating ways :
A:Steam Heating ,if you already have steam boiler ,only choose one autoclave ,if you don’t have steam boiler ,you can choose electricity heating steam autoclave
B:Hot air heating :Indirectly heating ways . You can choose steam inside coil or thermal oil inside coil

A:Steam heating way feature :

Steam temperature ,pressure ,time is controlled by electrical automatic control. It is one new energy saving bricking steam autoclave . It can get good working efficiency. The steam procedure can design as raise temperature ,Automatic pressure maintaining , automatic pressure relieving device, automatical control the time . We can revised the steam time ,pressure temperature ,pressure . After design procedure ,don’t need worker. When it finished ,the worker can take it out directly . Save worker and energy . Reduce company 35% cost
B:Hot air heating feature :
Indirectly heating vulcanization autoclave adopt automatic control trmperature and pressure,curing time .Special customized thermal radiator ,quick thermal conductivity ,good heat disipation ,long time use liftime .The steam entry the tank’s radiator by two group automatic valve,the radiator is arraged around the up ,down ,left ,right side according to caculation .High temprature fan via circulation wind plate to make the heat disperse from the back to the front .the heat get the autoclave door then return back to fan guide .collect wind guide cover make the tank air to be more uniformity and dissusion ,heat cycle back and forth inside the tanks, uniform temperature, temperature uniformity without dead angle, constant pressure. Solving products because of uneven distribution of temperature and pressure in the tank, and product quality is not the same.
2.Open door method: manual quick open door method. Turn the hand wheel, you can easily open or close the door and one person can easily complete all the steps. Use a special material bearings and accessories, long time use without deformation and damage. Safe, efficient, simple, efficient and save labor. When the power outage normal open or close the door.
3.Sealing way: Inflatable silicone ring seal. When working with compressed air automatic inflatable seal, as long as there is pressure inside, tank door does not leak out, and the greater the pressure, sealing the better. After pressure relief, seal ring automatic return flange seal groove. Inflatable seal design make seal ring not easy to wear, more convenient to use, easy to maintain, sealing effect significantly better than the other way, long seal life.

4.Safety interlocking methods of the door of the tank: Automatic pressure safety interlocking method and Manual safety interlocking method, it solved the safety problem of wrong operation.
5. Temperature control method: Using intelligent automatic computer control. The temperature data collected by the temperature sensor sent to the computer control box. And real-time display on the LCD panel, easy and intuitive. Operating temperature can be independently set according to the product desired temperature. Automatically open valve to heat when lower than the temperature, when reach the temperature automatically close the valve, to ensure the accuracy and stability of the tank temperature. Temperature values directly display, easy and intuitive, easy operator viewing. Depending on the product of the process, users can set their own curing process and procedures. (Can store 9 kinds of processes, each process can be set up eight heating and heat preservation periods).

Only you need autoclave ,we can customize for you according to your demand ..Pressure ,temperature ,diameter and length .

1.What is the max size can you do?
Reply:According to your product size to customize.Diameter from 800 mm to 1500mm.

2.How many products can you treat for one circle ?
Reply:According to your product size and packages size.

3.How long to finish one circle ?
Reply:Generally is one hours. is up to your products’ packing and product details.

4.Is it manual or automatic operation ?
Reply:We have full automatic type and semi-automatic type.

5.Can we install the equipment by ourselves ?
Reply:Of course ,we have full set drawing which will send to you after order.

6.lf your engineer is aviliable to oversea to install ?
Reply:,if you need ,we can arrange the engineer to install for you.
