- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Customization
-
Copper Thickness:
-
0.5-5.0oz
-
Min. Hole Size:
-
0.1mm
-
Min. Line Width:
-
3mil
-
Min. Line Spacing:
-
3mil
-
Surface Finishing:
-
Immersion Gold, HASL
-
layer:
-
1 to 32
-
Warranty:
-
12 Months
-
Soldering Standard:
-
IPC-610 CLASS C, CLASS D
-
Special Technique:
-
Blind &buried via+Impedance
-
Quantity:
-
Prototype, Low, Medium, High Volume PCB Assembly,
-
Type of Assembly:
-
SMT, Thru-hole, Cable assembly, Wire Harness
-
Solder Type:
-
Water Soluble Solder, Lead-Free, Wave soldering
-
Profiling Punching:
-
Routing,V-CUT,Beveling
-
Types of Service:
-
Turn-key, Partial turn-key or consignment, pilot run
-
Component packaging:
-
Cut Tape, Tube ,Reels, Loose Parts
Quick Details
-
Base Material:
-
FR-4
-
Board Thickness:
-
0.21-7.0mm
-
Model Number:
-
009
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Customization
-
Copper Thickness:
-
0.5-5.0oz
-
Min. Hole Size:
-
0.1mm
-
Min. Line Width:
-
3mil
-
Min. Line Spacing:
-
3mil
-
Surface Finishing:
-
Immersion Gold, HASL
-
layer:
-
1 to 32
-
Warranty:
-
12 Months
-
Soldering Standard:
-
IPC-610 CLASS C, CLASS D
-
Special Technique:
-
Blind &buried via+Impedance
-
Quantity:
-
Prototype, Low, Medium, High Volume PCB Assembly,
-
Type of Assembly:
-
SMT, Thru-hole, Cable assembly, Wire Harness
-
Solder Type:
-
Water Soluble Solder, Lead-Free, Wave soldering
-
Profiling Punching:
-
Routing,V-CUT,Beveling
-
Types of Service:
-
Turn-key, Partial turn-key or consignment, pilot run
-
Component packaging:
-
Cut Tape, Tube ,Reels, Loose Parts
| 1 | Description | pcb specification |
| 2 | Material | FR4 / HTG 150-180 FR4 / CEM-1 / CEM-3 / Aluminum |
| 3 | Layer | 1-20 |
| 4 | Board thickness | 0.2mm - 4.0mm |
| 5 | Board thickness tolerance | +/-10% |
| 6 | Copper thickness | 17.5um - 175um (0.5oz-5.0oz) |
| 7 | Min trace width | 0.15mm |
| 8 | Min space width | 0.15mm |
| 9 | Min drilling width | 0.20mm |
| 10 | PTH copper thickness | 0.4-2.0mil (10-50um) |
| 11 | Tolerance of etching | ±1mil (±25um) |
| 12 | V-cut angle | 25°, 30°, 45°, 60° |
| 13 | Pearl strength of line | ≥ 6lb / in(≥ 107g/mm) |
| 14 | Impedance control and tolerance | 50Ω±10% |
| 15 | Twist & Wrap | ≤0.5% |
| 16 | Soldermask | green, red, blue, white, black, yellow |
| 17 | Surface finish / plating | HASL / Lead free HASL/OSP/Gold Plating / Immersion Gold / ENIG |
| 18 | Applicantion |
all electronic devices |
| 19 | File | Protel 99se/P-CAD/Autocad/Cam350 |
| 20 | Inner packing | vacuum packing, plastic bag |
| 21 | Outer packing | standard carton packing |
| 1 | Quantity | prototype, low volume below 1K, big volume up to 1K |
| 2 | Type of assembly | SMT and thru-hole |
| 3 | Solder type | water soluble solder paste, leaded and lead-free |
| 4 | Components |
passive down to 0201 size BGA and VFBGA leadless chip carries/CSP Double-sided SMT Assembly Fine pitch to 08 mil BGA repaire and reball Part removal and replacement-same day service |
| 5 | Bare board size |
smallest: 0.25*0.25 inches largest:20*20 inches |
| 6 | File formats |
BOM (bill of material) PCB Gerber file Pick and place file |
| 7 | Type of service | Turnkey, partial turnkey or consignment |
| 8 | Components packaging |
Cut tape Tube Reels Loose parts |
| 9 | Turn time | same day -15 days service |
| 10 | Testing |
Flying Probe test X-Ray inspection AOI test |
Other Services:
Since 2000, certified by ISO9001, Fumax is an Electronic Contract Manufacturing company which offers complete solutions for design & engineering, materials sourcing & procurement, PCBA (Printed Circuit Board Assembly), box building (plastic or metal enclosure), final assembly and order shipment etc.
Q: Why working with Fumax?
A: 1.Sign NDA (Non-disclouser Agreement) for All customers
2. Protect customer's copy right
3. small- to medium-volume are welcome
4. purchase all components based on client BOM list
5. One-stop turnkey solution
Q: What you need to provide for quote?
A: For OEM
1. BOM (Bill of Materials) & Gerber files
2.Testing Method
3.Software if need programming
For ODM
1. Detail funtion requirements of the project you want to development.
2. Board size /layers requirement
Q: How to contact us?
A: Send your inquiry details in the below. Click "Send" Now!
