Quick Details
-
Feed Mechanism:
-
Walking Foot
-
Place of Origin:
-
China
-
Brand Name:
-
LVBU
-
Power:
-
750W
-
Overall Dimensions:
-
155*140*132cm
-
Weight (KG):
-
340 KG
-
Sewing size:
-
600*400mm
Quick Details
-
Type:
-
Industrial Sewing Machine
-
Max. Sewing Thickness:
-
6mm
-
Stitch Length:
-
1-12.7MM
-
Feed Mechanism:
-
Walking Foot
-
Place of Origin:
-
China
-
Brand Name:
-
LVBU
-
Power:
-
750W
-
Overall Dimensions:
-
155*140*132cm
-
Weight (KG):
-
340 KG
-
Sewing size:
-
600*400mm
Product Description
Specification
|
NO.
|
Type of Controller
|
Computerized Control System for Mitsubishi Series Pattern-sewing Machine
|
|
1
|
Sewing Area
|
X(Lateral) Direction Y(Longitudinal) Direction
SC442HG： 600(mm) x 400(mm) |
|
2
|
Max. Sewing Speed
|
2800rpm（with stitch interval below 3mm）
|
|
3
|
Stitch Length
|
0.1～12.7mm, and in the control system is of version 5.0 or above, the maximum stitch length can extend to 40 mm（Min Resolution:
0.10mm） |
|
4
|
Feed Motion of Frame
|
Intermittent feeding (2-shaft driven by pulse motor)
|
|
5
|
Needle Bar Stroke
|
41.2mm
|
|
6
|
Needles
|
DP×5、DP×17
|
|
7
|
Lift of Frame
|
Standard 18mm to Max. 22mm（Pneumatic type: Max. 25mm）
|
|
8
|
Intermediate Presser
|
Stepping Driving (Range: 0～8mm)
|
|
9
|
Lift of Intermediate Presser
|
20mm
|
|
10
|
Rotating Shuttle
|
Double-capacity semi-rotary hook
|
|
11
|
Memory of Pattern Data
|
Memory/U Disk
|
|
12
|
Pause function
|
Stop the machine during the sewing
|
|
13
|
Scaling Up/Down Function
|
Allows a pattern to be scaled up/down on the X axis and Y axis independently when user sews a pattern. Ratio: 1% to 400% (0.1% per
step) |
|
14
|
Scaling Up/Down Method
|
Increasing / decreasing stitch length & Increasing / decreasing stitch number
|
|
15
|
Sewing Speed Limitation
|
200～2800rpm（100rpm per step）
|
|
16
|
Pattern Selection Function
|
Pattern No. selection method
|
|
17
|
Up counter
|
No Count/Count of Pattern /Count of Cycle (0～99999)
|
|
18
|
Down Counter
|
No Count/Count of Pattern /Count of Cycle (0～99999)
|
|
19
|
Sewing Machine Motor
|
Servo Motor
|
|
20
|
Stop Needle at Highest Position Function
|
After the completion of sewing, the needle can return to its highest position.
|
|
21
|
Rated Power
|
600W
|
|
22
|
Operation Temperature Range
|
0℃～45℃
|
|
23
|
Operation Humidity Range
|
35%～85% （No Dew Condensation）
|
|
24
|
Line Voltage
|
AC 220V ± 10%；50/60Hz
|
Details Images
Walking trails
Guide rail on the top of the walk, so that the machine running flat and stable, not stuck machine
.
Walking trails .
Guide rail on the top of the walk, so that the machine running flat and stable, not stuck machine
Startup Mode 1 .
Pedal mode to start the seam
Startup Mode 2 .
Manual button start sewing
Secondary wire clamping device, decorated wire trace beautiful
Motor lift medium pressure foot, program setting, automatic high and low pressure foot, the same pattern thickness can be sewn at the same time
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
