Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FUWIT
-
Supplier Type:
-
Factory direct supply
-
Model:
-
FU-H5
-
Material:
-
ABS+PC shell
-
Battery Model:
-
CR2032
-
Bluetooth Version:
-
Bluetooth 4.2 Dual Mode
-
Size:
-
65.38*42.98*5.7mm
-
Antenna:
-
50ohm
-
Frequency Range:
-
2.4 GHz
-
Protection grade:
-
IP65
-
Transmission Range:
-
120m
Quick Details
-
Chipset:
-
nRF52832, nRF52832
-
Application:
-
Personnel tracking and positioning
-
Model Number:
-
FU-H5
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FUWIT
-
Supplier Type:
-
Factory direct supply
-
Model:
-
FU-H5
-
Material:
-
ABS+PC shell
-
Battery Model:
-
CR2032
-
Bluetooth Version:
-
Bluetooth 4.2 Dual Mode
-
Size:
-
65.38*42.98*5.7mm
-
Antenna:
-
50ohm
-
Frequency Range:
-
2.4 GHz
-
Protection grade:
-
IP65
-
Transmission Range:
-
120m
Product description
The FU-H5-BeaconX Pro is a portable tag with RFID and 3-axis accelerometer sensor，which can advertise iBeacon, Eddystone and Sensor datas.
It has a compact and thin structure design, accurate hardware and robust firmware, which can be used for employee attendance,access control, identity identification, location tracking, etc, and can realize remote cloud data management.
All parameters of FU-H5-BeaconX Pro can be modified, and all sensor data can be checked to meet different application requirements.Please check out our BeaconX Pro app, available for iOS and Android.
Product Parameters
|
Product Name
|
FU-H5 Bluetooth Wristband Beacon
|
|
Working frequency
|
2.4GHz
|
|
BLE Protocol
|
4.2/5.0
|
|
Material
|
ABS+PC & TPU
|
|
Dimensions (L*W*H)
|
65.38mm*42.98mm*5.7mm
|
|
Battery capacity
|
Button cell 550mA
|
|
Waterproof Level
|
IP 67
|
|
Chipset
|
Nordic nRF52832
|
|
Bluetooth Version
|
Bluetooth 4.2 Dual Mode
|
|
Operation Voltage
|
1.8~3.6V
|
|
Antenna
|
50ohm
|
|
Storage Temperature
|
-5℃~+35℃
|
|
Operating Temperature
|
-25 to +75
|
|
Transmission Range
|
120m
|
|
Single package size
|
19*11*9 cm
|
|
Single gross weight
|
1.000 kg
|
|
Package Type
|
32pcs for each box 10 boxes for each carton (320pcs) About 8KG for each carton
|
Product Usage
How to use it
Load the URL onto beacon
If you'd like to set up your own Physical Web beacon, you can follow these steps below
1. Download the beacon configuration app MokobeaconX from Google Play or Apple store;
2. Open beaconX Pro, and connect the beacon.
3. Click the device icon, select the SLOT 3 (URL), and enter the URL slot, then Click'Save' to save the changes as below image.
If you'd like to set up your own Physical Web beacon, you can follow these steps below
1. Download the beacon configuration app MokobeaconX from Google Play or Apple store;
2. Open beaconX Pro, and connect the beacon.
3. Click the device icon, select the SLOT 3 (URL), and enter the URL slot, then Click'Save' to save the changes as below image.
Product feature
Firmware and chipset
* Programmed MOKO standard MkBeaconX firmware;
* Ultra-low power consumption chipset NORDIC® nRF52 series with 32 bit ARM® Cortex-M4 CPU.
Compatibility
* Compatible with Apple iBeacon and Google Eddystone;
* Compatible with standard Eddystone Configuration GATT Service;
* Compatible with all Bluetooth® 5.0 devices.
* Programmed MOKO standard MkBeaconX firmware;
* Ultra-low power consumption chipset NORDIC® nRF52 series with 32 bit ARM® Cortex-M4 CPU.
Compatibility
* Compatible with Apple iBeacon and Google Eddystone;
* Compatible with standard Eddystone Configuration GATT Service;
* Compatible with all Bluetooth® 5.0 devices.
Trigger function
* H5-BeaconX Pro Supports button trigger and motion trigger;
* Control the device to start advertising all the time, stop advertising, or advertise for a while.
Custom made mounting
* Keychain / neck chain;
* Logo and color customizable;
* RFID customizable；
* NFC customizable；
* Provided with your own configuration.
* H5-BeaconX Pro Supports button trigger and motion trigger;
* Control the device to start advertising all the time, stop advertising, or advertise for a while.
Custom made mounting
* Keychain / neck chain;
* Logo and color customizable;
* RFID customizable；
* NFC customizable；
* Provided with your own configuration.
