Quick Details
-
Brand Name:
-
Guangte
-
Fiber Type:
-
G652 G657
-
Wavelength:
-
1064nm 1310nm 1550nm 1625nm 1650nm 780nm
-
Package:
-
4 port 3 port
-
Size:
-
Mini size
-
Application:
-
OTDR CATV
Quick Details
-
Type:
-
Fiber Pigtails
-
Model Number:
-
GT-CIR
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Guangte
-
Fiber Type:
-
G652 G657
-
Wavelength:
-
1064nm 1310nm 1550nm 1625nm 1650nm 780nm
-
Package:
-
4 port 3 port
-
Size:
-
Mini size
-
Application:
-
OTDR CATV
fiber optical 1310nm 1550nm 1625nm
3 Port 4 Port Polarization Maintaining Optical Circulator PM Fiber Circulator
Features
Low Insertion Loss & PDL
High Isolation & High Return Loss
Optical Path Epoxy Free
Application
Fiber Optic Amplifier
CATV Fiberoptics Link
Fiberoptic Systems Testing
Fiberoptic LAN Systems
OTDR
|
Parameter |
Test Condition/unit |
Specifications |
|
|
Operating Wavelength |
wavelength , nm |
1310nm ±30 or 1550nm ±30 |
|
|
Isolation |
dB |
≥40 |
|
|
Insertion Loss |
dB |
≤1.3 (Typ. 1.0) |
≤1.3 (Typ. 1.0) |
|
Light Path |
dB |
1→2,2→3,3→1 |
1→2,2→3,3→4,4→1 |
|
PDL |
dB |
≤0.2 |
|
|
PMD |
ps |
≤0.2 |
|
|
Return Loss |
dB |
≥50 |
|
|
Directivity |
dB |
≥50 |
|
|
Crosstalk |
dB |
≥50 |
|
|
Power Handling |
mW |
500 |
|
|
Fiber Type |
|
SMF-28e |
|
|
Operating Temperature |
Top, 0 C |
-5~ +70 |
|
|
Storage Temperature |
0 C |
-40 ~ +85 |
|
|
Dimensions |
nm |
100 X 80 X 10 |
|
|
N (N>4) Port circulator available upon request |
|||
